Summary of Contents for Di-LOG DL6413
- Page 1 Operating Instructions for AC TRMS CLAMP METER 61010-1 CAT IV 600V Please read this manual before switching the meter on. Important safety information included.
- Page 2 Di-LOG Di-LOG ...measurably better ...measurably better DL6413 Operating Manual DL6413 Operating Manual Contents Page I. Certificate of conformity As the manufacturer of the instrument listed below, we I. Certificate of Conformity declare under our sole responsibility that the product: II. Safety III.
- Page 3 Di-LOG Di-LOG ...measurably better ...measurably better DL6413 Operating Manual DL6413 Operating Manual II. Safety II. Safety (Continued) International Safety Symbol • If the equipment is used in a manner not specified by the This symbol, adjacent to another symbol or terminal,...
- Page 4 EMC regulations (SI 2016 No. 1091), the Low Voltage Regulation (described in the standard EN 61010-1) The DL6413 meets the standard (2012/19/EU) WEEE Directive in the UK & EU. This marking indicates that this product should not be disposed with other household wastes throughout the EC.
- Page 5 Di-LOG Di-LOG ...measurably better ...measurably better DL6413 Operating Manual DL6413 Operating Manual V. Meter Description VI. Symbols Used on LCD Display DC - Direct Current Current Clamp Non-Contact AC Voltage Detector Light Minus Sign Clamp Trigger AC - Alternating Current...
- Page 6 Di-LOG Di-LOG ...measurably better ...measurably better DL6413 Operating Manual DL6413 Operating Manual VII. Detailed Specifications: Range & Accuracy 1. General Specifications Clamp Size Opening 1.4” (35mm) Approx. Diode Test Test current of 0.3mA typical; Open circuit voltage 3.2V DC typical Continuity Check Threshold <= 50 Ω;...
- Page 7 • Rotate the functional dial to the either ACV or DCV position. Rotate the functional dial on the side of the DL6413 • Connect the test leads in parallel to the circuit from the off position clockwise to the function required.
- Page 8 Detection may not be • Rotate the functional dial to the VAC/Hz/% possible when measuring metal plated switches position, the DL6413 is default set to diode measuremen. or sockets. • Press the MODE button until “Hz or %” appears at •...
- Page 9 • Press the RANGE button. The “Auto Range” play. A long press of the REL/Backlight button will display indicator will turn off and the DL6413 will turn the backlight on/off. enter “Manual Range” mode. Zeroing Out Offsets: If your meter has a small offset or if •...
- Page 10 19. Warranty & Calibration • To hold the measured reading on the LCD display, Di-LOG instruments are subject to stringent quality press the data hold button. The data hold button is controls. If in the course of normal daily use a fault located on the right side edge of the meter.
- Page 11 AC TRMS CLAMP METER Instruction Manual Register your product with us to keep in contact with the latest updates and service reminders. Stay connected with us and be the first to know about our latest news and updates by following us on our social media channels.
