- Page 1 Installation Instructions / Warranty Porter’A Handshower Holder...
-
Page 2: Installation Instructions
Porter’A Handshower Holder The Porter’A handshower holder is suitable for use with handshowers using hoses with conical nuts. Tools required Grease pencil or other marking device Drill with 6 mm bit suitable for wall surface phillips head screwdriver slot head screwdriver silicone sealant Installation Consideratons: The screws and anchors included with this set are suitable for use in tile or... - Page 3 Drill the holes. Install the anchors. Seal the wall around the anchors using a silicone sealant. Screw the mounting bracket into the top anchor only. Use the second screw to attach the Porter’A holder through the mounting bracket to the bottom anchor.
-
Page 4: Adjust The Tension
Adjust the Tension It is possible to adjust how hard or how easy it is to change the angle of your Porter’A handshower holder. Remove the cover (if necessary) by sliding it upwards. Use a slot-head screwdriver to turn the adjustment screw - clockwise to make movement easier, counter-clockwise to make it harder. - Page 5 Lifetime Limited Consumer Warranty...
