Icom IC-2730A Service Manual page 36

[MAIN UNIT]
REF PARTS
NO. NO.
C1310 4030017460 S.CER C1005 JB 1H 102K-T
C1311 4030017460 S.CER C1005 JB 1H 102K-T
C1314 4030017650 S.CER C1005 CH 1H 270J-T
C1315 4030017650 S.CER C1005 CH 1H 270J-T
C1316 4030017360 S.CER C1005 CH 1H 030B-T
C1317 4030016930 S.CER C1005 JB 1A 104K-T
C1318 4030017460 S.CER C1005 JB 1H 102K-T
C1319 4030017460 S.CER C1005 JB 1H 102K-T
C1320 4030017460 S.CER C1005 JB 1H 102K-T
C1321 4030017460 S.CER C1005 JB 1H 102K-T
C1322 4030017460 S.CER C1005 JB 1H 102K-T
C1323 4030017460 S.CER C1005 JB 1H 102K-T
C1324 4030020000 S.CER C1005 JB 1A 105K-T
C1325 4030018860 S.CER C1005 JB 0J 105K-T
C1326 4030017460 S.CER C1005 JB 1H 102K-T
C1328 4030017460 S.CER C1005 JB 1H 102K-T
C1329 4030017460 S.CER C1005 JB 1H 102K-T
C1330 4030017460 S.CER C1005 JB 1H 102K-T
C1331 4030016930 S.CER C1005 JB 1A 104K-T
C1332 4030017030 S.CER C1005 JB 1A 273K-T
C1333 4030019550 S.CER C1608 JB 1E 334K-T
C1334 4030019560 S.CER GRM21BB31C106KE15L
C1336 4030017460 S.CER C1005 JB 1H 102K-T
C1340 4510010230 S.ELE 10 CE 1000 LX
C1343 4030019550 S.CER C1608 JB 1E 334K-T
C1344 4030019560 S.CER GRM21BB31C106KE15L
C1346 4030017030 S.CER C1005 JB 1A 273K-T
C1487 4510010240 S.ELE 16 CE 680 LX
C1488 4030017600 S.CER C1005 CH 1H 080C-T
C1500 4030017650 S.CER C1005 CH 1H 270J-T
C1501 4030017460 S.CER C1005 JB 1H 102K-T
C1502 4030017460 S.CER C1005 JB 1H 102K-T
C1503 4030017460 S.CER C1005 JB 1H 102K-T
C1504 4030017460 S.CER C1005 JB 1H 102K-T
C1505 4030017460 S.CER C1005 JB 1H 102K-T
J1 6510014961 S.CON B2B-ZR-SM4-TF(LF)(SN)
J100 6510023110 CON 3008L-8P8C <KIN>
J101 6450001440 CON HSJ1403-01-010
J102 6510025940 CON PJ-3047S <XIN>
J103 6510014961 S.CON B2B-ZR-SM4-TF(LF)(SN)
J300 6510025950 CON PCB-606(6P6C) BLACK <VKH>
J301 6510029570 S.CON 20P5.0-JMCS-G-B-TF(N)
W1 7030014230 JUM RJ20S0OHM
W300 8900016020 CAB OPC-1671 <TJM>
EP1 6910014690 S.BEA MPZ1608S221A-T
EP2 6910018460 S.BEA MMZ1005Y102C-T
EP6 6910018460 S.BEA MMZ1005Y102C-T
EP100 6910018460 S.BEA MMZ1005Y102C-T
EP101 6910018460 S.BEA MMZ1005Y102C-T
EP102 6910018460 S.BEA MMZ1005Y102C-T
EP103 6910018460 S.BEA MMZ1005Y102C-T
EP104 6910018460 S.BEA MMZ1005Y102C-T
EP105 6910018460 S.BEA MMZ1005Y102C-T
EP106 6910018460 S.BEA MMZ1005Y102C-T
EP107 6910018460 S.BEA MMZ1005Y102C-T
EP111 6910014690 S.BEA MPZ1608S221A-T
EP113 6910018460 S.BEA MMZ1005Y102C-T
EP115 6910014690 S.BEA MPZ1608S221A-T
EP118 6910018460 S.BEA MMZ1005Y102C-T
EP200 6910018460 S.BEA MMZ1005Y102C-T
EP201 6910018460 S.BEA MMZ1005Y102C-T
EP202 6910018460 S.BEA MMZ1005Y102C-T
EP300 6910018460 S.BEA MMZ1005Y102C-T
EP304 6910018460 S.BEA MMZ1005Y102C-T
EP305 6910018460 S.BEA MMZ1005Y102C-T
EP306 6910018460 S.BEA MMZ1005Y102C-T
EP312 6910018460 S.BEA MMZ1005Y102C-T
EP315 6910018460 S.BEA MMZ1005Y102C-T
EP316 6910018460 S.BEA MMZ1005Y102C-T
EP320 6910018460 S.BEA MMZ1005Y102C-T
EP324 6910018460 S.BEA MMZ1005Y102C-T
EP351 6910018460 S.BEA MMZ1005Y102C-T
EP352 6910018460 S.BEA MMZ1005Y102C-T
EP357 6910018460 S.BEA MMZ1005Y102C-T
EP358 6910018460 S.BEA MMZ1005Y102C-T
EP360 6910018460 S.BEA MMZ1005Y102C-T
EP361 6910018460 S.BEA MMZ1005Y102C-T
EP362 6910018460 S.BEA MMZ1005Y102C-T
EP363 6910018460 S.BEA MMZ1005Y102C-T
EP364 6910018460 S.BEA MMZ1005Y102C-T
EP409 6910014690 S.BEA MPZ1608S221A-T
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T
T
B
B
B
B
B
T
B
T 112.2/104.1
T
T
T
T
T 128.0/26.4
T 131.4/28.3
T 134.4/26.7
T 134.2/28.3
B 118.2/75.1
B 119.1/79.0
B
B
T 100.7/105.7
B 101.4/70.6
B 107.6/95.0
B 104.6/94.8
B 120.7/73.7
B 110.3/83.2
T
B
B
B
B
B
T 126.7/12.9
T 90.2/118.2
B 123.4/80.5
T 130.1/21.4
T 102.1/113.6
T 94.7/116.6
T
T
T
T
T
T
T
T
T
T 116.8/105.5
T 127.7/110.2
T 133.3/109.3
T 127.7/109.3
B
B
B
T 131.6/12.4
B 131.9/51.0
B 131.9/47.8
T 127.3/55.2
T 130.3/26.7
T 128.7/25.1
T 128.4/17.8
T 129.3/17.8
B 134.0/21.5
T 117.9/67.5
T 130.2/12.4
T 131.8/17.8
T 132.8/17.8
T 131.4/26.7
T 132.0/25.1
T 132.5/26.7
T 125.0/12.0
T 126.7/12.0
T 94.7/120.5
H/V
54.1/13.7
40.7/13.7
44.3/6.3
44.0/9.6
46.1/7.1
58.3/8.5
70.9/4.9
49.6/2.5
51.6/6.9
47.8/47.3
46.8/46.4
93.9/73.0
94.7/68.6
99.9/95.0
96.9/94.8
20.6/55.5
45.2/35.0
39.0/35.6
38.1/34.3
38.5/27.0
40.1/27.0
68.5/73.1
14.8/12.7
15.9/12.7
17.8/12.7
18.7/12.7
23.6/2.7
24.7/5.7
23.6/3.6
26.3/7.7
40.7/36.8
40.6/29.4
39.7/29.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6-11
S.=Surface mount
