3. Set the deadstart panel for a coldstart (refer to Setting the Deadstart Pane!).
• Select the correct deadstart function.
• Select the correct CMRDECK.
• Select the correct LIBDECK.
• Select appropriate system devices unless CMRDECK and! or IPRDECK
modification is to be performed.
All fields on the deadstart panel which are variable for coldstart are indicated by blanks in
the following illustration. For reference, fill in blanks with values used most frequently.
1 111 101
2 111 111
3 000 000 000
4
010
100 000 000
5 010 100
6 111 111
7 001 100 000
10 111 100
11 111 001
12
111
110 .110 100
13
14
15 000 000 000
OOOt
16 Not currently used.
it
17
Not currently used.
it
20
Not currently used.
it
4. Press the deadstart switch (refer .to System Deadstart Procedures).
5. Insert card deck in card reader and activate card reader as follows:
• Press MOTOR POWER.
• Select AUTO MODE.
• Press RELOAD MEMORY.
• Press READY.
6. Initialize the system and initiate job processing (refer to Initializing the System
and Initiating Job Processing).
WARMSTART PROCEDURES
The following summary provides a brief overview of the procedures necessary to warmstart
from a 667 or 669 magnetic tape unit. The operator may wish. to use this as a checklist
during warmstart and refer to the panel settings in step 3 for the appropriate variable fields.
Note that the tape unit on which the deadstart tape is to be mounted must be on a channel
without a PPU.
t
CDC CYBER 170 Series only.
t t
Words 16, 17, and 20 of the CDC CYBER 170 Series deadstart p'anel are reserved for
future use. Their settings have no .effect on the deadstart process.
60435600 A
2-3
