Cordless, Rechargeable Vacuum Cleaner; Owner’s Guide Household Type Note: Charge 14-16 hours before first use. Thank you for purchasing your new Eureka vacuum! Important instructions For easy assembly, please take a few moments to read this owner’s guide. If you have questions about your...
“call • This vacuum cleaner creates suction. the Eureka Customer Service HELPLINE Keep hair, loose clothing, fingers, and all at 1-800-282-2886. parts of body away from openings and •...
Dust cup filter (inside dust cup) Handle grip Handle Handle bolt Power on to charging stand Charge light for unit or extra battery Wall bracket / counter bracket Charger plug Lock button Plastic anchors Wall screws Eureka Customer Service HELPLINE 1-800-282-2886...
How to assemble your vacuum cleaner Assemble completely and charge batteries for 14-16 hours before using. CAUTION : Use only Eureka model JOD-S-100020A5-C-3 charger. Have a screwdriver available for assembly (not included). Attach Handle Grip (Fig. 1) Step 1: Locate the 2-part bolt in the assembly package.
Step 2: To use on bare floors or area rugs, make sure that handle is attached to the cleaner body (Fig. 7). Step 3: To use as a handvac remove handle releasing the lock button (Fig. 8). Fig. 8 Eureka Customer Service HELPLINE 1-800-282-2886...
Step 6: Replace filter frame in dust cup by pushing the seal located at the top in firmly to ensure proper filter performance. Replace a dirty or torn filter. Order additional dust cup filter, part number 61544. Fig. 11 Fig. 12 www.eureka.com...
Step 4: Push the battery down into the cleaner until it snaps securely into place. CAUTION: To avoid risk of fire, use Eureka battery pack, part number A07021501. Fig. 13 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
Step 3: If the cleaner will not operate after cooling for approximately 30 minutes, call 1-800-282-2886 for customer service or take it to a Eureka Authorized Service Center for repair. This cleaner is designed to pick up dirt and dust particles. Avoid picking up hard or sharp objects that could damage the vacuum cleaner.
You will be responsible for any initial shipping What Eureka will do: and insurance charges if the defective product(s) Eureka will, at its option, repair or replace a must be shipped for warranty service or warranty defective vacuum or vacuum part that is covered evaluation;...
