METAL DuCTwORK INSTALLATION
5
5. Remove backing from mounting plate
adhesive gasket.
7
7. Secure the mounting plate using (8) #8 self-
tapping screws.
9
9. Secure the unit to the mounting plate with
(4) #8-32 nuts.
(CONTINUED)
6
6. Center openings and press mounting plate onto
duct. The adhesive gasket will hold the mounting
plate in place.
8
8. Insert unit into opening. Be sure the air will pass
though the ActivePure cell honeycomb matrix.
10
10. Plug unit into working power receptacle.
Hard wiring unit into HVAC system
should be done by a licensed
HVAC installer or electrical
contractor only.
