Protection
Status indicators
Environmental operating
range
Storage temperature range
Physical
Overall dimensions
Mounting dimensions
Panel depth
Weight
Listed by

Safety considerations

Disconnect electrical power to the i-Vu Open Link before wiring it. Failure to follow this warning could cause
electrical shock, personal injury, or damage to the controller.
i-Vu Open Link
Incoming power and network connections are protected by non-
replaceable internal solid-state polyswitches that reset themselves
when the condition that causes a fault returns to normal. The power
and network connections are also protected against voltage
transient and surge events.
LED status indicators for Port S1 and S2 communication, Ethernet
Port E1 communication, and low battery status. Seven segment
status display for running, error, power status, archive valid, and
brownout.
0 to 140° F (-18 to 60°C), 0 to 90% relative humidity, non-
condensing
-24 to 140°F (-30 to 60°C), 0 to 90% relative humidity, non-
condensing
Rugged aluminum cover, removable, screw-type terminal blocks
A: 7-1/2 in. (19.1 cm)
B: 11-3/8 in. (28.9 cm)
C: 5 in. (12.7 cm)
D: 10-7/8 in. (27.6 cm)
E: 1-1/4 in. (3.2 cm)
F: 1/4 in. (12.7 cm)
Mount with 6-32 by 1/2 in. mounting screws
2 in. (5.1 cm)
1.4 lbs (0.64 kg)
UL916 (Canadian Std C22.2 No. 205-M1983, CE, FCC Part 15 -
Subpart B - Class A
