GPL-2000PT-KIT G.hn 2000 Powerline Pass-Through Kit
A
Understanding the G.hn 2000 Powerline Pass-Through Adapter
Security Button
Enables Device
Synchronization in Secure
Mode
Reset Button
Press for more than 10
seconds for Factory Reset
LED
Color
Power LED
Green
Off
Green
Connection LED
Orange
Red
Off
Security LED
Green
Off
Etherent LED
Green
Off
Quick Install Guide
Mode
Description
On
The Adapter is powered on.
Off
The Adapter is powered off or faulty.
On
The current connection (line rate) is more than 40Mbps.
On
The current connection (line rate) is between 5Mbps and 40Mbps.
On
The current connection (line rate) is less than 5Mbps.
Off
An Adapter connection does not exist.
On
The Adapter is secure (it has received or generated network keys).
Blinking
The Adapter is in the process of being secure.
Off
The Adapter is not secure.
On
An Ethernet LAN connection is established.
Blinking
Data over the Ethernet LAN connection is being transmitted.
Off
An Ethernet LAN connection is not established.
LED Icons
Descriptions are
provided below.
Ethernet Port
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for NexusLink GPL-2000PT-KIT
Summary of Contents for NexusLink GPL-2000PT-KIT
-
Page 1: Ethernet Port
Quick Install Guide GPL-2000PT-KIT G.hn 2000 Powerline Pass-Through Kit Understanding the G.hn 2000 Powerline Pass-Through Adapter Security Button LED Icons Enables Device Descriptions are Synchronization in Secure Mode provided below. Ethernet Port Reset Button Press for more than 10 seconds for Factory Reset... - Page 2 Initial Powerline Adapter Setup NOTE: A minimum of two G.hn Powerline Adapters are required. Follow Step 3-5 to add and secure additional G.hn Adapters to your network. 1. Plug one Powerline Adapter into a power outlet near your Network Device (Modem, Router, or Access Point). For maximum performance, please plug the Powerline Adapter directly into the wall outlet.
- Page 3 Network Device (Modem, Router, or Access Point) Set-Top-Box Pairing the Powerline Adapters 5. Press the Security Button on one Adapter until you see the Security LED start blinking GREEN. Then press the Security Button on the second Adapter until you see the Security LED start blinking GREEN.
- Page 4 Reset Button for more than 10 seconds (until all the LEDs of the device blink). Power Specifications: ADDITIONAL HELP: I/P: 100-240Vac, 50/60Hz, 15A • O/P: 100-240Vac, 50/60Hz, 15A • Visit the GPL-2000PT-Kit Product Webpage for additional resources such as a User Manual, WARNING FAQs, and/or Videos. For indoor use only • Link: nexuslinkusa.com/product/gpl-2000pt-kit Do NOT open the casing •...
