NexusLink GPL-1200POE Quick Install Manual

GPL-1200POE G.hn Powerline Adapter with Power over Ethernet
A

Getting to Know Your G.hn Powerline Adapter

LED Color
Green
Orange
Connection
Red
Ethernet
Green
Security
Green
PoE Green
Quick Install Guide
LED Descriptions Below
Configuration Button*
Mode Description
On The current connection (line rate) is more than 40Mbps.
On The current connection (line rate) is between 20Mbps and 40Mbps.
On The current connection (line rate) is between 1Mbps and 20Mbps.
Off An Adapter connection does not exist.
Blinking Adapter is in Power Saving Mode (blinks twice every 5 seconds).
On An Ethernet LAN connection is established.
Blinking Data over the Ethernet LAN connection is being transmitted.
Off An Ethernet LAN connection is not established.
On The Adapter is paired in Secure Mode.
Blinking The Adapter is in Configuration Mode.
Off The Adapter is not paired in Secure Mode .
On The Ethernet Port has PoE Mode Enabled.
Off The Ethernet Port does not have PoE Mode Enabled.
Blinking The Ethernet Port "PoE Mode" is in over-load or short.
Ethernet
Port
*
Press for 10 seconds for Factory Reset.
Page 1
B
