ITEMS NEEDED

The following items are required to build
or maintain your Enduro Trail Truck.
• 2mm Allen Wrench (#1501)
• 2.5mm Allen Wrench (#1503)
• Pliers
• Long Nose Pliers
• 5.5mm Nut Driver (#1507)
• 7mm Nut Driver (#1508)
OTHER HELPFUL ITEMS
The following items aren't required, but will
aid in the building and maintaining of your
Enduro Trail Truck.
• Threadlock (#1596) *Not Included
• Green Slime (#1105) *Not Included

INTRODUCTION

Thank you for purchasing this Element RC product. This assembly manual contains instructions and tips for building
and maintaining your new Enduro chassis. Please take a moment to read through this manual to help familiarize
yourself with these steps. We are continually changing and improving our designs; therefore, actual parts may appear
slightly different than in the illustrations. New parts will be noted on supplementary sheets located in the appropriate
parts bags.

ENDURO BUILDERS KIT

A performance rig built to endure. When hitting the trail, you want to do it with confi dence and the answer is
the all new Enduro Builders Kit!
At the heart of the Enduro is our revolutionary Stealth® X gearbox. Although the exterior appears to have a
conventional 3-gear transmission look, the inside is far from conventional. The Stealth® X features the ability to
adjust the rear drive ratio independently from the front drive in 3 levels. Stock overdrives the front end 5.7%,
option 1 provides a one-to-one drive ratio front to rear and option 2 overdrives the front end 11.83%.
Feeding the power to the tires are 3-piece telescopic driveshafts with an extruded aluminum center section,
universal front drive axles, and hardened steel ring and pinion gears. For the Builder's Kit, we decided to also
include machined steel versions of the 5.7% and 11.83% transmission gears. With the Enduro drivetrain, delivering
useful and reliable power will not be an issue.
We relocated the steering link assembly from the conventional location, to behind the axle (BTA). This feature
greatly improves approach angle and front end clearance, making rough terrain much easier to handle.
Knowing that every build is different we gave you the ability to choose what wheelbase you want to suit most
bodies on the market. The included optional rear links allow builders to choose between a 12.3, 12.0 and 11.8-inch
(313mm, 305mm and 299mm) wheelbase.
With all this packed in one box, we know the Enduro Builder's Kit is ready for the trail – Are you?

FEATURES

• Behind-the-axle (BTA) steering
• Aluminum steering plates
• Integrated servo winch mount
• Threaded aluminum shock bodies
• Adjustable rear 4-link bars
• Machined steel drive gears
• CMS [Chassis Mounted Servo]
• Adjustable front track bar
• Universal front drive axles
• Stamped steel frame rails
• Enclosed receiver box
• 12mm wheel hexes
• Adjustable front and rear bumper mounts
• Adjustable width rock sliders
• Two battery boxes
33.664760, -117.676533
• Aluminum Motor Plate
• Adjustable body posts
• Optimized ball cups for more fl uid axle
articulation
• Adjustable rear shock mount positions
• Telescopic driveshaft's front and rear
• Extruded aluminum driveshaft splines
• One-piece rear axle design
• Splined front axle with adjustable caster
• Machined input pinion gear
• Metal ring gear
• Machined steel top shaft
• Machined metal idler gears
• Heavy duty 5mm diameter steel links
• Metal ball bearings included
