Rear Axle Build: Bag 6 - Associated Electrics Element RC Enduro Owner's Manual

33.664760, -117.676533
GATE 03
FRONT AXLE BUILD: BAG 5
x4 25211
3x10mm
BHCS
x1 42064
Steering Plate,
Right
NOTE: Install left and
right side wheel hexes
GATE 02

REAR AXLE BUILD: BAG 6

NOTE: Install left and
right side drive shafts
GATE 01
LINKS BUILD: BAG 7
x2 42041
Pivot Ball,
6mm
x2 42040
Rod End,
Curved
x1 42064
Steering Plate,
Left
42019
x1
Wheel Hex
Pin, 2x11mm
x1 42069
Wheel Hex,
6mm
x1 42068
Drive Shaft,
Rear, 80mm
x1 42043
Link,
83mm
112.50mm
GATE 01
x4 41086
2.5x16mm,
SHCS
x1 91560
5x10x4mm
Bearing
31531
x2
3x6mm
BHCS
25187 x1
3x14mm
BHCS
REAR AXLE BUILD: BAG 6
42065 x1
Ring Gear,
91474 x2
30T
7x14x3.5mm
Bearing
91560
x2
5x10x4mm
Bearing
71032
x2
2.5x14mm
SHCS
x1 42060
Lower 4-Link
Mount
NOTE: Install left and right side
axle mounts and wheel hexes
89203 x1
3x16mm
BHCS
09
x1 42060
Axle Housing,
Differential Cover
x1 42066
Pinion Gear,
8T
x1 42061
Axle Housing,
Rear
x1 42019
Wheel Hex
Pin, 2x11mm
x1 42069
Wheel Hex,
6mm
