Chassis Build: Bag 1, 2 - Associated Electrics Element RC Enduro Owner's Manual

YOUR BUILD BEGINS HERE.
GATE 01

CHASSIS BUILD: BAG 1, 2

31531 x1
3x6mm
BHCS
31532 x1
3x8mm
BHCS
x2 25211
3x10mm
BHCS
x1
42001
x1
Bumper Mount
Rear
GATE 02
CHASSIS BUILD: BAG 1, 2
GATE 03
CHASSIS BUILD: BAG 1, 2
42005
x1
Shock Mount
(Right, Rear)
25211 x2
3x10mm
BHCS
42002 x1
Battery
Mount
42000
Chassis Rail
Left
42005
Shock Mount
(Left, Rear)
x2 25211
3x10mm
BHCS
42006
x1
Floor Board
x2 25211
3x10mm
BHCS
x1 31532
x4 25203
3x8mm
3x12mm
BHCS
FHCS
x1 42001
31532 x1
Bumper Mount
3x8mm
Front
BHCS
25211 x2
3x10mm
BHCS
31532 x1
3x8mm
BHCS
x1
x1
x1 42000
Chassis Rail
Right
x1 42005
Shock Mount
(Right, Front)
x1 31532
3x8mm
BHCS
25203
x4
3x12mm
FHCS
x1 42006
Floor Board
x1 42002
Chassis Brace
Rear
25211
x2
3x10mm
31531 BHCS
x1
3x6mm
BHCS
31532
3x8mm
BHCS
89202
x2
3x12mm
BHCS
05
x1 42005
Shock Mount
(Left, Front)
42004
x1
Servo
Mount
x1 42004
Gearbox
Mount
x1 42008
Rock
Slider
NOTE: Install Left and
Right side Rock Sliders
