Gearbox Build: Bag 4 - Associated Electrics Element RC Enduro Owner's Manual

33.664760, -117.676533
GATE 01

GEARBOX BUILD: BAG 4

x4 31350
2.5x10mm
FHCS
GATE 02
GEARBOX BUILD: BAG 4
42025 x2
Idler Shaft Pin
2x9mm
42025
x1
Stealth X Gearbox
Idler Shaft
42031 x1
Stealth X Idler
Gear, 27T,
Machined
GATE 03
GEARBOX BUILD: BAG 4
42029 x1
Stealth X Gearbox
Motor Plate
25201
x3
3x8mm
FHCS
42032
x1
FT Stealth X
Drive Gear, 53T,
Machined
42027
x1
Stealth X Gearbox
Outdrive, Long
91563 x2
10x15x4mm
Bearing
x1 42031
Stealth X Idler
Gear, 28T,
Machined
Stealth X Gearbox
Top Shaft, Rear
91560
x4
5x10x4mm
Bearing
Stealth X Gearbox
Spur Gear Hub
25391
FT M4 Locknut
x1 42027
Stealth X Gearbox
Drive Gear Shim
42032
x1
FT Stealth X
Drive Gear, 52T,
Machined
41078 x5
3x28mm
BHCS
42030
x1
42023
x1
Stealth X Gearbox
Case
31532
3x8mm
BHCS
42023 x2
x1
x4
42027
x1
Stealth X Gearbox
Outdrive, Short
NOTE: There are optional
gearbox builds on page 24
42023
x1
Stealth X Gearbox Stealth X Gearbox Stealth X Gearbox
Case
x2 91563
10x15x4mm
Bearing
Over Drive Option 1 (Stock)
Motor x1
*
Not Included
x2
x2 7337
.250x.125x.015"
x1 9654
Washer
Spur Gear
48P, 87T
07
41077
2.5x14mm
FHCS
20T 28T 52T
27T 53T
