:: Introduction

:: Introduction :: Introduction :: Introduction
Thank you for purchasing this Team Associated Qualifier Series product. This manual contains
instructions and tips for maintaining your new Pro SC 4x4 RTR. Please take a moment to read
through it and familiarize yourself with these steps as they will help you to understand each
component's function and show you some tips for getting the most out of your Pro SC 4x4 RTR.
We are continually changing and improving our designs; therefore, actual parts may appear
slightly different than the illustrations.
For more information, scan the QR code to the right for videos and
tutorials on the Pro SC 4x4 RTR!
http://www.teamassociated.com/cars_and_trucks/Pro_SC_4x4/
:: Pro SC 4x4 Platform Features
• Ready-To-Run shaft drive 4wd Short Course truck
• Reedy 550-SL 3500kV 4-Pole Brushless Motor
• Splash-proof Reedy SC800-BL brushless speed control with High Current T-plug Connector
(2S-3S LiPo compatible)
• Reedy WolfPack 3000mAh 8.4V NiMH Battery with High Current T-plug Connector
• XP 2.4Ghz Radio system with XP Metal Gear steering servo
• Factory painted and decaled Short Course body, available in two color combinations
• 16mm 'Big Bore' composite fluid filled shocks
• 15-spoke off road hex drive wheels with high-grip racing tires
• Short Course style front and rear bumpers and improved adjustable body mounts
• Upgraded CVAs and rear dog bones for improved durability
• Heavy duty gear differentials, aluminum drive shaft, and center slipper clutch
• Composite modular chassis with enclosed water-resistant receiver box
• All metric hardware, adjustable steel turnbuckles, and ball bearings throughout
:: Additional Items Needed
Your Pro SC 4x4 RTR requires the following items to complete your kit:
• Transmitter batteries (x6 AA) (#302 recommended)
• Battery charger (peak detection charger recommended) (AE #610) -OR- Wall charger (#29154)
:: Other Helpful Items
• Silicone Shock Fluid / Differential Fluid (Refer to catalog for complete listings)
• Body Scissors (AE Part # 1737)
• FT Hex Wrenches (AE Part # 1541, 1655)
• FT Nut Drivers (AE Part # 1561, 1663-1668)
• FT Turnbuckle Wrench (AE Part #1112)
• Green Slime shock lube (AE Part # 1105)
• Needle nose pliers
• Ride Height Gauge (#1449 recommended)
Associated Electrics, Inc.
26021 Commercentre Dr.
Lake Forest, CA 92630
http://www.TeamAssociated.com · http://www.RC10.com · http://twitter.com/Team_Associated · http://bit.ly/AEonFacebook
• FT Threadlock (AE Part # 1596)
• Multi Tool (AE Part # 7494)
• Calipers or a Precision Ruler
• Soldering Iron
• Wire cutters
• Reamer/hole punch
• Hobby knife
Customer Service
Tel: 949.544.7500
Fax: 949.544.7501
