  • Page 1 BUILDER’S KIT OWNERS BUILD MANUAL...
  • Page 2 For the Builder’s Kit, we decided to also include machined steel versions of the 5.7% and 11.83% transmission gears. With the Enduro drivetrain, delivering TEAM ASSOCIATED is a Registered Trademark of Associated Electrics, Inc. useful and reliable power will not be an issue.
  • Page 3 33.664760, -117.676533 HARDWARE 1:1 SCALE VIEW HARDWARE USED WITH OPTIONAL REPLACEMENT PART NUMBERS FLAT HEAD SCREWS (FHCS) SOCKET HEAD SCREWS (SHCS) SHIMS AND WASHERS 2.5x10mm (31350) 2x5mm (31511) .250x.125x.015 (7337) Aluminum (8566) 2x8mm (7187) 2.5x14mm (41077) Servo Horn Spacer (42041) 3x8mm (25201) 5.5x0.5mm (31381) Aluminum (8553)
  • Page 4 33.664760, -117.676533 TABLE OF CONTENTS 8/26/2019 COVER DRIVESHAFTS BUILD (BAG 8) INTRODUCTION SHOCKS BUILD (BAG 9) 1:1 HARDWARE “FOLD OUT” BODY POSTS BUILD (BAG 10) TABLE OF CONTENTS NOTES CHASSIS BUILD (BAG 1, 2) CATALOG ELECTRONIC MOUNTS BUILD (BAG 3) OPTIONAL GEARBOX BUILD GEARBOX BUILD (BAG 4) TRAIL TIPS...
  • Page 5 YOUR BUILD BEGINS HERE. GATE 01 CHASSIS BUILD: BAG 1, 2 25211 42001 42005 25203 31532 3x10mm Bumper Mount Shock Mount 3x12mm 31531 3x8mm BHCS Front (Left, Front) FHCS BHCS 3x6mm BHCS 25211 3x10mm 31532 42006 BHCS 3x8mm Floor Board BHCS 31532 25211...
  • Page 6 GATE 01 ELECTRONIC MOUNTS BUILD: BAG 3 NOTE: There is an optional 71050 “standard pack” sized battery Hook and 25203 tray included! Loop Straps 3x12mm FHCS 42003 Battery Box, Shorty Pack GATE 02 ELECTRONIC MOUNTS BUILD: BAG 3 Receiver Not Included 42007 6727 Receiver...
  • Page 7 33.664760, -117.676533 GATE 01 GEARBOX BUILD: BAG 4 42032 FT Stealth X Drive Gear, 53T, Machined 41077 2.5x14mm FHCS 42027 Stealth X Gearbox 42027 Outdrive, Short 42027 Stealth X Gearbox Stealth X Gearbox Outdrive, Long Drive Gear Shim 31350 42032 2.5x10mm FT Stealth X FHCS...
  • Page 8 GATE 04 GEARBOX BUILD: BAG 4 1336 Pinion Gear 42023 *Not Included Stealth X Gearbox Gear Cover 25225 3x3mm Set Screw *Not Included NOTE: Make sure the gear mesh 31530 between the spur gear and pinion 89208 25201 3x5mm has a slight amount of movement 3x14mm 3x8mm BHCS...
  • Page 9 33.664760, -117.676533 GATE 03 GATE 01 FRONT AXLE BUILD: BAG 5 REAR AXLE BUILD: BAG 6 42060 42065 25211 Axle Housing, Ring Gear, 3x10mm 91474 Differential Cover BHCS 7x14x3.5mm Bearing 42064 Steering Plate, Right 42064 Steering Plate, Left 42019 Wheel Hex 42066 Pin, 2x11mm Pinion Gear,...
  • Page 10 GATE 02 LINKS BUILD: BAG 7 42041 42041 Servo Horn Spacer Pivot Ball, 25187 42043 3x14mm Link, BHCS 73mm 42040 Rod End, Curved NOTE: Check the rod end angles before installation 102.20mm 25215 M3 Locknut, 2308 Black 3x18mm BHCS GATE 03 LINKS BUILD: BAG 7 41078 3x28mm,...
  • Page 11 33.664760, -117.676533 GATE 05 LINKS BUILD: BAG 7 25188 NOTE: Build and install 42041 3x20mm, two rear upper links Pivot Ball, BHCS 41078 3x28mm BHCS 42044 Link, 42040 108mm Rod End, Curved Wheelbase Chart Wheelbase (in/mm) Upper Length 11.8” / 299.7mm 3.78”...
  • Page 12 GATE 01 DRIVE SHAFT BUILD: BAG 8 42020 42021 42020 42021 31532 Gearbox Side Drive Shaft, Drive Shaft, Female Drive Shaft 3x8mm Male, CVA (33mm, 42mm) Pin, 2x11mm BHCS 42020 Axle Side 42020 42021 Pin Retainer, Drive Shaft 42021 Long Barrel Drive Shaft, 42020...
  • Page 13 33.664760, -117.676533 GATE 01 SHOCK BUILD: BAG 9 42081 42081 Shock O-Ring, Piston Shock Cap 42082 Shock Body, 10x32mm 5407 6299 O-Ring, E-Clip 42040 Enduro 42081 Rod Ends Shock O-Ring 42083 Spacer Shock Shaft, 3x30mm 42085 NOTE: Build 4 Shock Bottom Cap, complete shocks Blue Aluminum GATE 02...
  • Page 14 GATE 04 SHOCK BUILD: BAG 9 42041 42041 Pivot Ball, Pivot Ball, Upper Shock Upper Shock 7337 7337 .250 x .125 x .015 in. .250 x .125 x .015 in. Washer Washer 89203 89203 3x16mm 3x16mm BHCS BHCS 25187 25187 3x14mm 3x14mm BHCS...
  • Page 15 33.664760, -117.676533 Notes...
  • Page 16 Shocks 5407 O-Rings, Red, Silicone 6299 E-Clipp, 1/8” 42040 Enduro Rod Ends 42041 Enduro Pivot Balls Set 42054 FT Enduro Pivot Ball, Steel 42055 FT Enduro, Shock Bushing, Steel 42085 42079 Enduro Shock Parts, Black Aluminum 2 ea. 42080 6299 Enduro Shock Parts 4 ea.
  • Page 17 33.664760, -117.676533 Motor Mount 1336 18T 48P Aluminum Pinion 7337 Washers, .250 x .125 x .015 9654 Spur Gear, 87T, 48P 31530 25201 M3x8mm FHCS 25225 M3x3mm Set Screw 25391 25391 FT M4 Locknuts, Blue 42023 9654 31530 M3x5mm BHCS 42023 31532 M3x8mm BHCS...
  • Page 18 Battery Tray/Radio Box 2308 M3x18mm BHCS 25225 6338 Antenna Tube and Cap 1 ea 7337 Washers, .250 x .125 x .015 6338 25203 25202 M3x10mm FHCS 25203 M3x12mm FHCS 42007 25203 25215 M3 Locknut 25202 25225 M3x3mm Set Screws 25202 31532 M3x8mm BHCS 7337...
  • Page 19 33.664760, -117.676533 Front Axle 25211 25187 M3x14mm BHCS 25211 M3x10mm BHCS 25187 25215 M3 Locknut 25187 41078 M3x28mm BHCS 25187 25187 41086 M2.5x16mm SHCS 42064 42064 41086 41086 91560 91560 42019 Enduro 2x11mm Pin 42060 25215 25215 Enduro Diff Cover and Lower 4-Link Mounts 42061 Enduro Axle Housing (Front, Rear) 1 ea.
  • Page 20 Wheel/Tire 25391 FT M4 Locknuts, Blue 41088 M2.6x10mm 42100 Enduro Method 701 Trail Series Wheel, 1.9” Bronze 42100 42101 Enduro Method 701 Trail Series Wheel, 42100 42106 1.9” Black 42102 FT Enduro Beadlock Rings, Brass 42103 FT Enduro Beadlock Hex Adapter, Aluminum 42104 FT Enduro Beadlock Hex Adapter, Brass 42106...
  • Page 21 33.664760, -117.676533 SHOCK FLUIDS OPTION PARTS 5420 10 Weight Silicone Shock Fluid 2oz. 42010 Enduro Bumper Mounts, Hard 5421 20 Weight Silicone Shock Fluid 2oz. 42013 Enduro Shock Mount Set, Hard 5422 42014 30 Weight Silicone Shock Fluid 2oz. Enduro Floor Board, Receiver Box, Hard 5423 40 Weight Silicone Shock Fluid 2oz.
  • Page 22 REEDY ELECTRONICS REEDY BATTERIES / CHARGERS MOTORS BATTERIES 27424 Reedy Radon2 Crawler 16T 5-Slot 1850kV Brushed Motor AA Alkaline 1.5V (4) 27430 Reedy Crawler 16T 5-Slot RTR Brushed Motor Wolfpack 3000mAh 7.2V w/T-Plug connector Wolfpack LiPo 3300mAh 30C 7.4V w/T-Plug (#730) ESC’s (SPEED CONTROLLERS) Wolfpack LiPo 4000mAh 35C 7.4V w/T-Plug (#731) 29199...
  • Page 23 33.664760, -117.676533 APPAREL / PROMOTIONAL TOOLS TEE SHIRTS 1111 FT Turnbuckle Wrench SP124* AE 2017 Worlds Tee, Black (S, M, L, XL-5XL) 1112 FT 4mm Turnbuckle Wrench SP126* 1114 Team Associated Tri T-Shirt, Black (S, M, L, XL-5XL) FT Dual Turnbuckle Wrench SP140* Reedy Heritage Tee, Black (S, M, L, XL-5XL) 1449...
  • Page 24 GATE 01 STEALTH X: BUILD CONFIGURATION: MOTOR MOUNT FACING REAR (STOCK) OVERDRIVE: Overdrive is a scenario where the front and rear wheels do not rotate at the same speed. The Stealth X gearbox is designed to allow the front wheels to spin faster than the rear wheels. Overdrive is advantageouse when climbing up rock faces because the front tires will want to pull the vehicle up the rock.
  • Page 25 33.664760, -117.676533 TRAIL TIPS AND CHECKLIST PREPARING TO HIT THE TRAIL: When preparing to hit the trail, it’s a good idea to have a checklist to make sure you have everything and don’t end up having to head back early. We’ve compiled a checklist of the things we think you’ll need on the trail. We’ve also left some space for you to add your specifi...
  • Page 26 ASSOCIATED ELECTRICS, INC. 26021 COMMERCENTRE DR. LAKE FOREST, CA 92630 USA CALL: (949) 544-7500 - FAX: (949) 544-7501 CHECK OUT THE FOLLOWING WEB SITES FOR ALL OF OUR KITS, CURRENT PRODUCTS, NEW RELEASES, SETUP HELP, TIPS, AND RACING INFO! WWW.ASSOCIATEDELECTRICS.COM...
