Troubleshooting guide
Problem
• Light will not
come on when
motion is
sensed.
• Light Comes on
in Daylight.
• Light Stays on.
• Light Flashes on
7
and off twice
when activated.
• Light comes on
irregularly
when motion is
sensed.
Technical specifications
Power Supply:
Maximum Switchable Load:
Time On Adjustment:
Environmental Protection:
Transmission Range:
Conforms to Directives:
Solution
1. The installation switch is turned off.
2. Light bulb is loose or burned out
3. Sensor is positioned too far from
receiver. Move Tx closer
1. Tx unit is installed in a dark
location.
2. Receiver is in Manual Override
Mode. Flip Transmitter wall switch Off
then On twice to place back into Auto
Mode
Receiver is in Manual Override. Flip
wall switch Off then ON twice to place
back into Auto Mode.
This is the Low battery signal. replace
batteries in the Transmitter.
2. The Tx unit is positioned too far
from receiver. Move Tx closer.
230 V AC ~ 50Hz
2000W (e.g. 4 x 500W
Tungsten Halogen)
1, 3, 5 and 12 minutes
IP44 (suitable for outdoor use)
Up to 100m (varies with
surrounding structures)
73/23/EEC and 89/336/EEC
