Installation - Time Guard TLRX05 Installation & Operating Instructions Manual

The In Line Receiver must be within transmission
range of your chosen transmitter. The In Line
receiver can be placed at any convenient break point of
the wiring connected to the luminaire it
is intended to control. We suggest that the Transmitter
is placed in its optimum position to give the coverage
and detection required, then the In Line receiver is
placed at a point where it can
receive the Transmitter`s signal. To ensure that the
Receiver is receiving the transmission signal. This will
be less than 100m away if walls or chain link fences
come between the Tx and Rx units - if there is any
doubt about whether communication will take place make
temporary installations before programming.

Installation

IMPORTANT
3
Switch off the electricity at the fuse box by removing
the relevant fuse or switching off the circuit breaker
before proceeding with the installation.
Remove the front cover of the TLRX05 by removing the
4 x cover fixing screws as (Fig A).
Mark position of the fixing holes. (Fig B).
Drill the holes. Insert the wall plugs into the holes.
PASS THE CABLE THROUGH THE INCOMING
AND OUTGOING CABLE GROMMETS BEFORE
FIXING THE UNIT TO THE WALL.
Allow approximately 100mm of cable to pass through
the grommet. (A template for this wire length is
provided on page 8 of this manual). Fit grommet into its
location hole ensuring a good seal.
Fix the unit to the wall. Take care not to overtighten the
screws to prevent damage to the mounting plate. If
using a power screwdriver, use the lowest torque
setting.
