Summary of Contents for Time Guard TLRX05
- Page 1 RECEIVER CONTROLLER Cat No. TLRX05...
- Page 2 Introduction The TLRX05 In Line Receiver is part of the Timeguard range of products which communicate by radio frequency (r.f.) signals. This enables substantial amounts of wiring to be eliminated which is particularly useful in long runs and coverage of outbuildings.
-
Page 3: Parts Included
Output cable to light Indicator Program/reset Time button ON/Test Mains supply Parts included • In Line receiver unit. • Instruction manual. Please keep safe for future reference. • Accessory Pack. Tools and parts needed • Electric/hand-held drill & bits. • Terminal or Electricians screwdriver. •... -
Page 4: Installation
Remove the front cover of the TLRX05 by removing the 4 x cover fixing screws as (Fig A). Mark position of the fixing holes. (Fig B). - Page 5 Connection Connect the incoming mains cable through one of the lower grommets and into the terminal block as follows (see connection diagram): NEUTRAL (Blue) EARTH (Green/Yellow) LIVE (Brown) Ensure the connectors are secure. Connect the cable connected to the switched luminaire through the upper grommet to the terminal block as follows (see connection diagram Fig B):...
- Page 6 Tx unit should be left connected. ** If introducing the TLTXK2 hand held transmitter press the “1” button on this unit to activate the TLRX05. ***If the button is pressed for 5 seconds or more then all the codes that have been learnt will be erased.
-
Page 7: Manual Override
After Programming, set the ON TIME dial. To set how long the lamp will remain ON after the TLRX05 hs received a signal from a Tx unit, set the ON TIME dial on the RX to 1, 3 , 5 or 12 minutes. See fig D. -
Page 8: Troubleshooting Guide
Troubleshooting guide Problem Solution • Light will not 1. The installation switch is turned off. come on when 2. Light bulb is loose or burned out motion is 3. Sensor is positioned too far from sensed. receiver. Move Tx closer •... - Page 9 Incoming Wire Template 75mm 3” 25mm 1” Use this template to estimate incoming cable length...
-
Page 10: Year Guarantee
5 Year Guarantee In the unlikely event of this product becoming faulty due to defective material or manufacture within 5 years of the date of purchase, please return it to your supplier in the first year with proof of purchase and it will be replaced free of charge. For years 2 to 5 or any difficulty in the first year telephone the helpline on 020 8450 0515.
