Connection
Connect the incoming mains cable through one of
the lower grommets and into the terminal block
as follows (see connection diagram):
NEUTRAL (Blue)
EARTH (Green/Yellow)
LIVE (Brown)
Ensure the connectors are secure.
Connect the cable connected to the switched
luminaire through the upper grommet to the
terminal block as follows (see connection
diagram Fig B):
NEUTRAL (Blue)
EARTH (Green/Yellow)
LIVE (Brown)
Ensure the connectors are secure.
Replace front cover and fully tighten the 4 fixing
4
screws as (Fig A).
N
L
N
L1
