Programming
Each Rx unit needs to learn the codes involved in the
messages from all the Tx units which are required to
control it (up to 20).
1 Turn OFF/remove batteries from any Tx unit which is not
required to control this RX unit. Turn off any other Rx units.
If it is convenient more than one Rx unit can learn the code of
a Tx unit simultaneously in which case leave these Rx units
switched ON.*
The Rx unit needs to be set in programme mode. This will
2
happen automatically up to 4 seconds after the Rx unit is
first powered up. It can also be set by pressing the
Programme/ Reset button for 1 to 2 seconds (pressing for 5
seconds or longer will erase all programming within the Rx
unit). In either case the Time On/Test control must be set to
Test which will give a 5 minute period of programme mode.
The lights under control of the Rx unit will turn on at the
start of this period indicating it is in progress.
5
Go to the Tx unit** to be introduced to the Rx unit and
3
move across the face of its PIR lens within detection
range causing it to detect (indicated by the lights under
control turning ON for most Tx units and by a flash
from the red LED on the TLTXDCB.
Return to the Rx unit and check that it has turned the
4
lamps under its control off (indicating correct code learning).
*Any other Rx units left connected should now be
checked in the same way.
Press the Programme/Reset button for 1 to 2 seconds*** if
the Rx unit is required to learn the code of another Tx unit.
*Any other Rx units required to learn the code of this
new Tx unit should be left connected.
** If introducing the TLTXK2 hand held transmitter
press the "1" button on this unit to activate the TLRX05.
***If the button is pressed for 5 seconds or more then all
the codes that have been learnt will be erased.
