Introduction
The TLRX05 In Line Receiver is part of the Timeguard
range of products which communicate by radio
frequency (r.f.) signals.
This enables substantial amounts of wiring to be
eliminated which is particularly useful in long runs
and coverage of outbuildings.
It is an In Line Receiver which receives r.f. signals from
transmitters it has been programmed to recognise and
turns connected lighting on.
In the following instructions products with catalogue
numbers including Tx (ones that send information
about PIR detection) are referred to as Tx units and
products with catalogue numbers including Rx (ones
that receive information about PIR detection) are
referred to as Rx units.
1
A
Wall fixing hole
C
Wall fixing hole
