5. If the lights did not go OFF in step 4 page 5 the Rx is
not picking up a signal. Check the radio signal path
between the Sensor and Receiver for any metal
obstructions (support beams, chain link fences etc).
These can block radio signals and interfere with signal
transmission. A way to check path if using the Battery
Powered Detector TLTXDCB is to set the Rx On time
dial to test, remove the sensor from its location and
walk the sensor around the Rx. As you walk, wave
your hand in front of the sensor Tx. Note when the it
turns the Rx light OFF, and re mount in that area.
Settings
After Programming, set the ON TIME dial.
To set how long the lamp will remain ON after the
TLRX05 hs received a signal from a Tx unit, set the ON
TIME dial on the RX to 1, 3 , 5 or 12 minutes. See fig D.
6

Manual override

The lamp can be turned on and off independently of
any transmission signal by switching the unit off/on
once in less than two seconds To return to Auto Mode
repeat this switching action.
Erasing all codes
Tx unit codes can be erased for reprogramming. To
erase codes, while the TLRX05 is powered, press and
hold the PROGRAM button for more than 5 seconds.
The light will turn on, go out and then turn on again.
This will clear the unit of all programmed codes and
place it back into the AUTO PROGRAMMING Mode.
Now return to the Programming Section.
