- Page 1 ProgramaSTAT U N D E R F L O O R H E A T I N G C O N T R O L L E R UFPT24 (24 hour) UFPT7 (7 day)
- Page 2 ON mode or in a timed ON period in Auto mode. Contents 1 ProgramaSTAT UFPT24 (24 hour) or UFPT7 (7 day) 2 Temperature Probe 3.5mm fixing screws General The ProgramaSTAT combines the elements of timeswitch, floor thermostat and frostat in a single compact, economical and stylish unit.
-
Page 3: Typical Application
Typical Application The ProgramaSTAT provides a total control package for electric underfloor heating up to 16A. Terminals are provided for connection of a temperature probe and heating mat or cable. These are connected as shown in figure 1. Basic Circuit Connection Non polarity conscious external temperature probe... - Page 4 Commissioning Switch ON the mains to the heating circuit, slide the mode selector to continuously ON, and turn the thermostat dial fully anticlockwise to maximum temperature. Both the heating ON indicator and the heating demand indicator will come ON (assuming the floor temperature is not above 30°C). If the thermostat dial is now gradually turned clockwise the heating demand indicator will turn OFF.
- Page 5 Battery This product has a factory fitted rechargeable battery. If the ProgramaSTAT is left with its mains power switched off for more than 1 month the display may go blank. In this case, switch mains on, wait 4 hours, and apply reset - see 1 before programming. Programming Only two setting buttons are required, <Change>...
- Page 6 1 To Reset Before Programming (To alter clock time or modify programmes - see section 5) To clear programmes from memory and reset the UFPT24 press and hold down both buttons until the display goes blank. Release buttons and display will fill with its complete range of characters and then clear to show clock and hour digit flashing.
- Page 7 ii Minute Setting - Press the <Program> button briefly to select the minutes - display shows clock symbol and minute digits flashing. Press the <Change> button to advance the minutes setting. For rapid minute selection press and hold down <Change> button. (Note: 16 hours shown as example of hours set) iii Press <Program>...
- Page 8 4. Programme Review To fast review the set programmes or for quick exit to normal operating mode - press and hold down the <Program> button. Normal review can be carried out by pressing the <Program> button briefly which reviews the clock time with the whole display flashing. Further brief pressing of this button reviews the programme ON and OFF times in sequence again with the whole display flashing.
- Page 9 UPFT7 Programming Instructions 24 hour digital Change Button clock display sets days, hours, and minutes and self cancelling override Programme Button used to select the clock CHANGE PROGRAM time and day and the 6 1 2 3 4 5 6 7 ON/OFF programme OFF AUTO times and days and to...
-
Page 10: Normal Operating Mode
Normal Operating Mode In normal operation the UPFT7 will display the correct day and its time with the colon flashing. The output status will be shown by either ON or OFF on the display. 1 To Reset Before Programming 1 2 3 4 5 6 7 (To alter clock time or modify programmes - see section 5) To clear programmes from memory and reset the UPFT7 press and hold down both buttons until the display goes... - Page 11 2 Setting Clock (after reset) Day Setting - Press <Change> button to advance to the day required. Day 1 = Monday and Day 7 = Sunday. ii Hour Setting - Press the <Program> button briefly to select the hours - display shows clock symbol and the hours digits flashing.
- Page 12 3. To Set Programme ON/OFF Times (after clock setting) The user is now able to set the day(s) that the first programme will operate on. The alternatives are: 1 2 3 4 5 6 7 G G G G G = 5 days (Weekdays) Mo Tu We Th Fr = 2 days (Weekend) Sa Su G G G G G G G...
- Page 13 vi Repeat steps i to v to set the remainder of the 5 programme ON/OFF times and day(s) as required. Note: Any unused ON/OFF programmes must be left blank and should be bypassed by pressing the <Programme> button until the display shows normal operating mode.
-
Page 14: Specifications
Self Cancelling Override To change the output status from ON to OFF or vice versa press the <Change> button. The output status will change and indicate override is in operation by flashing either the ON or OFF symbol on the display. The override will end at the next programmed change, or sooner, if the <Change>... -
Page 15: Year Guarantee
3 Year Guarantee In the unlikely event of this product becoming faulty, due to defective material or manufacture within 3 years of the date of purchase please return it to your supplier in the first year with proof of purchase and it will be replaced free of charge. - Page 16 HELPLINE 020-8450-0515 For a product brochure please contact: Timeguard Ltd. Victory Park, 400 Edgware Road, London NW2 6ND 020-8452-1112 or email csc@timeguard.com Designed and manufactured in the U.K. 67-058-124...
