Installation

The Master Clock is intended for wall mounting.
1. Screw in the upper fixing screw halfway and hang up the unit.
2. Screw in the two lower screws, accessible under the connection space cover.
3. Connect, if included, other accessories/options such as radio synchronisation.
4. Connect the supply voltage.
