Teradek VidiU mini Quick Start Manual

A
B
A:
Charge indicator
B: Battery Meter
C: Warning
D: Broadcast start/stop button
E: Status LED (ring)
POWER & CONNECT
Press Power, the Status LED flashes to indicate
1
VidiU mini is booting.
Connect video via micro HDMI.
2

GET ONLINE

iOS
Download the VidiU app from the App Store.
1
Ensure Bluetooth is enabled on your iOS device, then open
2
the VidiU app and select VidiU mini under the list of Bluetooth devices.
Select whether you wish to use your iOS device or another network
3
as VidiU's Internet connection.
* iOS device (Personal Hotspot): The network name is entered automatically.
Enter your hotspot's password, if configured, and press Connect. Activate the
iOS device's hotspot via the Settings menu and wait for it to confirm VidiU mini
is connected. Reopen the VidiU app.
* WiFi Network: If your iOS device is connected to a WiFi network, the Network
field will be completed automatically. Enter the WiFi network's password and
press Connect and click Done.
Select VidiU mini under WiFi Devices.
4
Android/PC
Connect to VidiU mini's WiFi network: VidiU−mini−XXXXX
1
(serial number of the device).
Open a web browser and navigate to http://172.16.1.1, or find the
2
device using Bonjour.
Enter the Settings menu and open the Network section to configure
3
VidiU mini's WiFi.
Once configured, connect your mobile device or computer to the same
4
network as VidiU mini.
Use the VidiU app (Android) or a Bonjour browser (PC/Mac) to find
5
VidiU mini's new IP address.
C D E
pantone 1795
F G H
I
F:
Micro−B USB DC Input
G: Micro HDMI Input
H: Power Button
I: Reset Button
pantone 355 pantone 307
1
2
