Teradek Prism Flex Mk II Quick Start Manual

Encoder/decoder
Hide thumbs Also See for Prism Flex Mk II:

Advertisement

Quick Links

Download this manual
Teradek User Manual
Prism Flex Mk II Quick Start Guide (2024)
With a flexible I/O and compact, low-SWaP design, Prism Flex Mk II easily fits into any workflow.
Prism Flex Mk II is perfect for placement on a tabletop, camera top, or wedged between your video
switcher and audio mixer. Prism Flex Mk II can encode or decode up to 4Kp60 video with stunning
10-bit 4:2:2 image fidelity. The Prism platform supports many common streaming protocols such
as TRT, SRT, MPEG-TS, RTSP/ RTP, and RTMP(S), and can be connected to Teradek's Core Cloud
platform for even more flexibility.
Prism Flex Mk II Quick Start Guide (2024)
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Prism Flex Mk II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teradek Prism Flex Mk II

Summary of Contents for Teradek Prism Flex Mk II

  • Page 1 With a flexible I/O and compact, low-SWaP design, Prism Flex Mk II easily fits into any workflow. Prism Flex Mk II is perfect for placement on a tabletop, camera top, or wedged between your video switcher and audio mixer. Prism Flex Mk II can encode or decode up to 4Kp60 video with stunning 10-bit 4:2:2 image fidelity.
  • Page 2 Teradek User Manual TABLE OF CONTENTS...
  • Page 3 1. Encoder: Turn your video source on, then connect the HDMI (I) or SDI input (M) from your video source to Prism Flex’s input connector. Decoder: Turn your monitor on, then connect the HDMI (I) or SDI output (L) from your Prism Flex to the monitor’s input connector. Prism Flex Mk II Quick Start Guide (2024) Page 3...
  • Page 4 • Modem screens (A and B) - Displays the carrier name and allows you to switch SIM cards • Firmware version: Displays the device name and firmware version. Hold to perform a factory reset. • Recording screen: Hold to enable or disable the recording function Prism Flex Mk II Quick Start Guide (2024) Page 4...
  • Page 5 Web UI The Prism WebUI allows direct control of all of Prism Flex’s video configuration, network settings, firmware, licenses, and recordings. Prism Flex Mk II Quick Start Guide (2024) Page 5...
  • Page 6 Teradek User Manual Prism App The Prism App allows you to configure all of Prism Flex’s settings, monitor your video, and contribute your phone's cellular internet connection to a Teradek Cloud Stream. The Prism App is available for Android devices and must be used with the Prism on an accessible network.
  • Page 7 MPEG-TS mode as an example. 1. Connect to the Prism Flex encoder (see previous section) and open the encoder’s web UI. 2. Open the Streaming menu, then select MPEG-TS as the streaming mode. Prism Flex Mk II Quick Start Guide (2024) Page 7...
  • Page 8 6. Open the Ingest menu, then select MPEG-TS as the ingest mode. 7. Enter the protocol, ensuring the selected protocol matches the Encoder’s protocol configuration (see step 3). Confirm the port is set as the default 9710. Prism Flex Mk II Quick Start Guide (2024) Page 8...
  • Page 9 Teradek User Manual Decoder Web UI CONNECTING TO CORE Core allows Prism Flex to be remotely controlled, utilize bonding protocols (Teradek Bonding Protocol and TRT) across multiple internet connections, and split the stream across multiple destinations. Visit https://corecloud.tv to learn more.
  • Page 10 In Core, under Sources select "Add Encoder", and and then select "Add a device using code" Settings Management in Core Once a connection is established, under Sources select the encoder and then press settings at the top right Prism Flex Mk II Quick Start Guide (2024) Page 10...
  • Page 11 Once a connection is established, under Sources select the encoder and then press the Blue "Regular Server" button Select a pre-provisioned video server. If the server is not online, the Prism will attempt to start it. Prism Flex Mk II Quick Start Guide (2024) Page 11...
  • Page 12 3. Configure the Recording Settings and if so desired turn on "On Streaming Event" to start the recording automatically when you begin 4. If manually controlled, press Start Recording at the top of the WebUI or the bottom of Prism App under Link iOS Device Prism Flex Mk II Quick Start Guide (2024) Page 12...
  • Page 13 • File will be uploaded after the recording is completed. OTHER RESOURCES • USER GUIDE ARTICLES: https://guide.teradek.com/m/109577 • PRISM FLEX FIRMWARE AND GUIDE PDFs: https://teradek.com/pages/downloads#prism-mobile • PRISM REFERENCE GUIDE PDF: https://teradek.com/pages/downloads#prism Prism Flex Mk II Quick Start Guide (2024) Page 13...
