- Page 1 INSTALLATION MANUAL GRUPPO INCASSO...
- Page 2 CONGRATULATIONS Congratulations and thank you for choosing a Falmec rangehood. To avoid the risks that are always present when you use an electrical appliance it is important that the rangehood is installed correctly and that you read the safety instructions carefully to avoid misuse and hazards.
- Page 3 Gruppo incasso 100: 15 kg Gruppo incasso 70: 12 kg Gruppo incasso 50: 10 kg 1017 / 739 / 494 780 / 502 / 257 1053 / 776 / 531 1029 / 751 / 506 HOLE MEASUREMENTS FOR INSTALLATION...
- Page 4 Gruppo incasso Green Tech 70: 13 kg Gruppo incasso Green Tech 50: 11 kg 739 / 494 502 / 257 776 / 531 751 / 506 HOLE MEASUREMENTS FOR INSTALLATION...
- Page 5 Gruppo incasso 70: 12 kg Gruppo incasso 50: 10 kg 739 / 494 502 / 257 776 / 531 751 / 506 HOLE MEASUREMENTS FOR INSTALLATION...
- Page 6 Installation measurements (1), wall unit hole (2), hood installation (3), fitting to the wall unit (4) Max 20 mm Min 12 mm (x4) (x4) (x4) Only for maint. MAGNET...
- Page 7 Only for Installation of check valve (5), suction pipe (6) and electrical connection (7) ø 15 ø 12 122mm 150mm...
- Page 8 Assembling standard active carbon filter: remove panel (8), remove metal filters (9), assemble active carbon filters (10). Green Tech...
- Page 9 How to uninstall: remove panel (11), remove metal filters (12), unscrew fixing screws (13), release built-in unit (14). Safety bracket (Pull!) (x4)
-
Page 10: Safety Instructions And Warnings
SAFETY INSTRUCTIONS Before installing the hood, check that the electrical mains power supply corresponds with what is report- AND WARNINGS ed on the identification plate located inside the hood. Installation operations are to be carried out The socket used to connect the installed equipment by skilled and qualified installers in accor- to the electrical power supply must be within reach: dance with the instructions in this booklet and in... -
Page 11: Intended Use
INTENDED USE INSTALLATION only intended for qualified personnel The equipment is solely intended to be used to extract fumes generated from cooking food in Before installing the hood, carefully read the chapter 'SAFETY non-professional domestic kitchens: any other INSTRUCTIONS AND WARNINGS' . use is improper. -
Page 12: Operation
The outlet pipe must have: The speeds are indicated by the • a diameter not less than that of the hood fitting. Increase speed from 1 to 4 LEDs on the keys: • a slight slope downwards (drop) in the horizontal sections to prevent conden- Speed 4 is only active for a few sation from flowing back into the motor. -
Page 13: Maintenance
DESCRIPTION OF TRANSMITTING COMMANDS • Press UP and DOWN simultaneously on the radio control for more than 5 seconds: reset is confirmed by three brief flashes of the display. • Reconnect the hood to the electrical power supply. Motor switch-on and speed increase •... - Page 14 LIGHTING The range hood is equipped with high efficiency, low consumption LED spotli- ghts with an extremely long life-span under normal use conditions. Should the LED spotlight need to be replaced, proceed as shown in the figure. DISPOSAL AFTER END OF USEFUL LIFE The crossed-out trash or refuse bin symbol on the appliance means that the product is WEEE, i.e.
