Car Solutions QROI2-RGB Installation Manual

Octa core q-roi2 rgb android navigation

Hide thumbs Also See for QROI2-RGB:

Table of Contents

Need help?

Do you have a question about the QROI2-RGB and is the answer not in the manual?

Page 2 •Specification INDEX CONTENS Android 5.1.1 (Lollipop) Nexell S5P6818 (Cortex-A53 Octa-Core CPU up to 1.6GHz) Memory DDR3 2GB up to 800MHz Internal Storage 8GB/16GB eMMC 5.1 Display OEM LCD / RGB / HDMI / CVBS Resolution 800 x 480 SD CARD Micro SD Slot Support (up to 64GB) UBLOX-8 (GPS + GLONASS)
Page 3 •Product Exterior •Components Power * 1ea Multi * 1ea B/T board * 1ea B/T Cable * 1ea (HPOWER0137) (HARETC0208) (QCPASS0481) (HARETC0209) R touch cable * 1ea RGB Out * 1ea GPS Antenna * 1ea Microphone cable * 1ea HTOUCH0022 (HRGBCA0025) (GPSANT0014) (MICPHO0002) Speaker * 1ea...
Page 4 •DIP SWITCH ※ ON : DOWN / OFF : UP •High resolution monitor with resistive touch panel •Low resolution monitor with resistive touch panel •High resolution monitor with Uart capacitive touch panel •High resolution monitor with QDIS capacitive touch panel •...
Page 5 •Installation Resistive touch panel Capacitive touch Resistive touch Capacitive touch panel Toggle (Option) HTOUCH0022 HTOUCH0036 MICROPHONE (Option) SPEAKER Interface HARETC0209 RGB Cable HDM Cable...
Page 6 •Setting ※ Directory : Setting→QROI Settings ① Status bar hide : Hide navigation bar located on the left ② Display Setting : ① Adjust the screen ② ③ Touch Calibration : Start touch calibration ③ ④ Start Application : ④ Select startup application When Qroi reboots ※...
