- Page 1 Update Date 2014.07.24 Model QNAVI3-1CH-MAIN-2.5 Firmware Date...
- Page 2 Warning / Precautions! Do not modify, dismantle or unintended operation this system outside Qnavi After Sales. Damage occurred by unintended operation Warning may cause Qnavi After Sales service void. Always wear seatbelt. When the vehicle is suddenly stop can cause injury. Warning ...
-
Page 3: Table Of Contents
Table of Contents 1. Features 2. Button Usage 3. How to use 3.1 Main Menu 3.2 Phone 3.3 Multimedia 3.3.1 Main 3.3.2 Music 3.3.3 Video 3.3.4 TDMB 3.3.5 AV 4. Setting 4.1 Main Menu 4.2 Rear Camera 4.3 Version 4.4 Volume 4.5 Start Program 4.6 Language 5. -
Page 4: Features
1. Features • Connect with various multimedia source (2*Video Input, 1*Rear Camera Input, 1*A/V Out) • Enable to input USB to play Music and Movies • PAS(Parking Assistance System) • Support full multimedia PIP(Picture in Picture) to maximize convenience • Enable to switch modes and control system via OEM buttons... -
Page 5: Button Usage
2. Button Usage ※ Functions of Buttons Switching modes (QNAVI↔OEM screen) Accept call / End call Go to Phone Menu Press 2 seconds or longer for restart program Press short, for OEM display Press 2-3 seconds longer, back to QNAVI ※... -
Page 6: How To Use
3. How to use 3.1 Main Menu ※ Select menu buttons via Touch screen ① Touch the UI to ② ③ switch OEM ④ ⑤ ① Battery Voltage: Move to Battery Voltage in Q-SMART ② NAVIGATION: Refer to the navigation manual ③... -
Page 7: Phone
3. How to use 3.2 Phone ① ② ③ ④ ① Contacts: phonebook and call log ② Settings : Phone pairing and Phonebook synchronization ③ To pick up phone or make phone call. ④ To end phone call ※ In order to use Phone function, It is required to have a Blue tooth set(Optional) - Page 8 3. How to use 3.2 Phone ① ② ① Call logs (Received voice calls, Dialed voice calls) ② Contact list.
- Page 9 3. How to use 3.2 Phone ① ② ③ ④ ① Pairing : Press “PAIRING” button and input the password (original setting : 0000), searching device through Bluetooth and choose the phone. ※ Pairing : Connect user’s mobile phone with QNAVI ②...
-
Page 10: Multimedia 3.3.1 Main
3. How to use 3.3 Multimedia / Main Menu ① ② ③ ⑤ ④ ① Music : Play music on the connected USB ② Movie : Play movie files on the connected USB ③ TDMB : Play DMB ④ External input : Play multimedia files from external device ⑤... -
Page 11: Music
3. How to use 3.3 Multimedia / Music Player ① ② ④ ③ ⑤ ⑧ ⑥ ⑦ ① PIP function (Music player window and navigation can be shown at the same time) ② Saved music list on the device ③ Repeat – Repeat playlist, Repeat one music, No repeat Comprise of 3 modes. -
Page 12: Video
3. How to use 3.3 Multimedia / Video Player ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ① PIP function (Video player window and navigation can be shown at the same time) ② Saved video list on the device ③ Skip to the previous ④... -
Page 13: Tdmb
3. How to use 3.3 Multimedia / TDMB ① ② ③ ④ ⑤ ① PIP Function : Enable to see DMB and Navigation at the same time. ② List of DMB Channel to play. ③ Search DMB / DAB Channel. ④... - Page 14 3. How to use 3.3 Multimedia / AV ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ※ Domestic model doesn’t support function ①~⑧ ① PIP function (Video player window and navigation can be shown at the same time) ② Turn of AV power ③...
-
Page 15: Setting
4. Settings 4.1 Menu Display ① ② ③ ④ ⑤ ⑥ ① Rear Camera : Setting rear camera ② Version : Hardware system and firmware version Factory Menu (only can be set by installer) ③ Volume : Adjust speaker volume ④... -
Page 16: Rear Camera
4. Settings 4.2 Rear Camera ① ② ① Set parking guide line ON / OFF ② Adjust the position of parking guide line... -
Page 17: Version
4. Settings 4.3 Version ① ② ③ ④ ⑤ ① FACTORY : Program upgrade and setting external devices ※ Only for installer-PW : 4291 (Not for User) ② INITIAL : QNAVI initialization ③ TOUCH CALIBRATION ④ UPGRADE ⑤ A/S MODE - QNAVI : QNAVI mode Usage - ORIGINAL : Original mode Usage(Only use QNAVI via touch) ※... - Page 18 4. Settings 4.3 Version / UPGRADE ※ Put latest upgrade files in SD Card, and insert the QNAVI - Check the Box you want to upgrade(among OS, APP, BT, FW). And select the START UPGRADE...
-
Page 19: Volume
4. Settings 4.4 Volume ② ① ① Reduce QNAVI volume ② Increase QNAVI volume... -
Page 20: Start Program
4. Settings 4.5 Start Program ① ② ① Select OEM or Q-Navi when turn on the ignition ② Select MAIN MENU or GPS when start the QNAVI... -
Page 21: Language
4. Settings 4.6 Language ① ② ① Set menu in Korean ② Set menu in English... -
Page 22: Trouble Shooting
5. Trouble Shooting When the displayed locations does not match your actual position • → It will take around 5 minutes to receive the GPS signal after a car turned off. Please wait for receiving GPS signal. • No voice direction guide in Navigation →... -
Page 23: Quality Warranty
6. Quality Warranty This product has been tested and have passed under our strict quality control. If the failure occurred due to the carelessness of workmanship within one year after the purchase, we are responsible to repair free of charge. Please bring this warranty to dealer whom you purchased this product from at the repair time. - Page 24 MEMO...
- Page 25 MEMO...
