Husqvarna LC 247Li Workshop Manual

Hide thumbs

Advertisement

Quick Links

Workshop manual
LC 247Li, LC 247iX, LC 347VLi,
LC 347iVX, LC 353iVX
English
361 - 001 -

Advertisement

loading

  Also See for Husqvarna LC 247Li

  Summary of Contents for Husqvarna LC 247Li

  • Page 1 Workshop manual LC 247Li, LC 247iX, LC 347VLi, LC 347iVX, LC 353iVX English 361 - 001 -...
  • Page 2: Table Of Contents

    4 Servicing data 4.1 LC 247Li, LC 247iX..........13 4.2 LC 347VLi, LC 347iVX......... 14 4.3 LC 353iVX............15 4.4 Motor on LC 247Li, LC 247iX, LC 347VLi, and LC 347iVX..............16 4.5 Motor on LC 353iVX..........17 5 Servicing tools 6 Function overview 6.1 Rating plate and product serial number....
  • Page 3: Introduction

    WARNING: All personnel that repair or do servicing on the product must read and understand the safety instructions in this workshop manual. 1.5 Servicing tools The manual gives information about necessary servicing tools. Always use original tools from Husqvarna. 361 - 001 - Introduction - 3...
  • Page 4: Safety

    Technical data chapter that have tension. and on the label. • Use only a Husqvarna Battery Series type of battery with this product. Obey the safety instructions that are given for the battery and battery charger. For Start procedure: push...
  • Page 5 Release motor brake handle to stop. Slow Fast Note: Other symbols/decals on the product refer to certification requirements for some markets. 361 - 001 - Safety - 5...
  • Page 6: Prepare And Do Servicing On The Product

    3 Prepare and do servicing on the product 3.1 Assembly 3. Fold the handle forward. 3.1.1 To assemble the handle 1. Loosen the lower knobs. 2. Move the knobs to the lower end of the grooves on the left and the right side of the product. 3.
  • Page 7 3.1.3 To set the product in operation position CAUTION: Do not set the cutting height too low. The blades can hit the ground if the surface of 1. Fold the handle to upright position. the lawn is not level. 3.1.5 To assemble the grass catcher 1.
  • Page 8 3.1.6 To assemble the mulch plug (accessory) 1. Lift up the rear cover and remove the grass catcher. 2. Put the mulch plug into the discharge channel. 3. Replace the blade with the mulch blade that is To remove and supplied in the mulch kit.
  • Page 9: Servicing Schedule

    3.2 Servicing schedule After each Every 10 Every 25 Maintenance task Before use hours hours Product Do a general inspection Clean the product Examine the drive wheels General lubrication Do a check of the start inhibitor Make sure that the safety devices on the product are not defec- tive Examine the cutting equipment Examine the cutting cover...
  • Page 10 On LC 347VLi and LC 247Li: The green LED (B) 7. Push the motor brake handle in the direction of the comes on. handlebar. 3.3.2 To use the drive on the wheels The two bars of the battery indicator come on •...
  • Page 11 1. Push the SavE button (A) to start the function. The green LED (B) comes on. 2. Push the ON/OFF button (A) on the control panel. a) On LC 347VLi and LC 247Li: The green LED (B) goes out. 2. Push the SavE button again to stop the function.
  • Page 12 3. Open the battery lid and turn the safety key to 0. 4. To remove the battery, push the 2 release buttons and pull out the battery. 5. Charge the battery if it is weak. 12 - Prepare and do servicing on the product 361 - 001 -...
  • Page 13: Servicing Data

    4 Servicing data 4.1 LC 247Li, LC 247iX 0.7 - 1.2 Nm 1.2 - 1.7 Nm 2.5 - 3.5 Nm 1.2 - 1.7 Nm 0.7 - 1.2 Nm 9.0 - 10.0 Nm 1.2 - 1.7 Nm 6.0 ~ 10.0 Nm 13 mm 6.0 ~ 10.0 Nm...
  • Page 14: Lc 347Vli, Lc 347Ivx

    4.2 LC 347VLi, LC 347iVX 0.7 - 1.2 Nm 1.2 - 1.7 Nm 2.5 - 3.5 Nm 1.2 - 1.7 Nm 0.7 - 1.2 Nm 9.0 - 10.0 Nm 1.2 - 1.7 Nm 6.0 ~ 10.0 Nm 13 mm 6.0 ~ 10.0 Nm 13 mm 9.0 - 10.0 Nm LC 347iVX...
  • Page 15: Lc 353Ivx

    4.3 LC 353iVX 0.7 - 1.2 Nm 1.2 - 1.7 Nm 2.5 - 3.5 Nm 0.7 - 1.2 Nm 9.0 - 10.0 Nm 1.2 - 1.7 Nm 1.2 - 1.7 Nm 6.0 ~ 10.0 Nm 13 mm 6.0 ~ 10.0 Nm 13 mm 9.0 - 10.0 Nm 25.0 ~ 28.0 Nm...
  • Page 16: Motor On Lc 247Li, Lc 247Ix, Lc 347Vli, And Lc 347Ivx

    4.4 Motor on LC 247Li, LC 247iX, LC 347VLi, and LC 347iVX 0.7 - 1.0 Nm 1.2 - 1.7 Nm 0.7 - 1.0 Nm 1.2 - 1.7 Nm 0.7 - 1.0 Nm 3.0 ~ 5.0 Nm 16 mm 1.2 - 1.7 Nm 1.2 - 1.7 Nm...
  • Page 17: Motor On Lc 353Ivx

    4.5 Motor on LC 353iVX 0.7 - 1.0 Nm 1.2 - 1.7 Nm 0.7 - 1.0 Nm 1.2 - 1.7 Nm 1.2 - 1.7 Nm 0.7 - 1.0 Nm 0.7 - 1.0 Nm 1.2 - 1.7 Nm 3.0 ~ 5.0 Nm 16 mm 1.2 - 1.7 Nm 1.2 - 1.7 Nm...
  • Page 18: Servicing Tools

    5 Servicing tools Item Description Use for Article number 13 mm Open Wrench Blade bolt T-handle Torx T40 Screw with torx head T-handle Torx T20 Screw with torx head 588 59 85-01 Snap ring pliers Snap rings Screwdriver, PH4 Screws Spring pull tool Disassemble springs 16 mm, Flexible socket wrench...
  • Page 19: Function Overview

    IPX1 LED 1 flashes The battery is empty. Charge the battery. HUSQVARNA AB, SE-561 82 HUSKVARNA, SWEDEN 6.3.2 To charge the battery Charge the battery before the first use. The battery is 6.2 Motor only 30% charged when supplied to the customer.
  • Page 20: Cutting Equipment

    Fully charged 4 are lit 6.4 Cutting equipment The LC 247Li, LC 247iX, LC 347VLi, LC 347iVX, and LC 353iVX can use a standard blade (A) together with a grassbag, or a mulch blade (B) together with a mulch- plug (accessory).
  • Page 21: Repair Instructions

    7 Repair instructions 7.1 Product overview for repair instructions LC 347VLi LC 247Li LC 247iX LC 353iVX LC 347iVX LC 347VLi LC 347iVX LC 353iVX 1. Blade 7. Safety key switch 2. Wheels 8. Control panel 3. Front axle 9. Start inhibitor 4.
  • Page 22: To Clean And Examine The Product Parts

    7.2 To clean and examine the product parts 8. Lock the blade with a block of wood. Attach the spring washer and tighten the bolt and washer with a • Clean and examine all parts fully. You find more torque of 23–28 Nm. instructions in the chapter for each part if special tools or procedures are necessary.
  • Page 23: Front Axle

    3. Remove dust cover (only LC 347VLi, LC 347iVX and 3. Remove the wheel and axis assembly. LC 353iVX). 4. Attach the wheels in the opposite sequence. Use the Servicing data on page 13 . correct torque. Refer to 7.5 Front axle 7.5.1 To disassemble and assemble the front axle 1.
  • Page 24: Gearbox

    7.6 Gearbox 4. Remove the dust cover. 7.6.1 To remove and install the gearbox (LC 347VLi, LC 347iVX and LC 353iVX) 1. Remove the hubcap. 5. Adjust the cutting deck to its highest position. To remove and attach 2. Remove the wheel. Refer to the wheels on page 22 .
  • Page 25 7. Remove the transmission cable. 10. Remove the screws. 11. Remove the link arm and tube as one unit. Remove the wheel axle. Servicing 8. Release the spring with a hook, refer to tools on page 18 . Hold the product with one hand. With your other hand, pull the hook quickly and with force to release the spring.
  • Page 26: Rear Axle

    7.7 Rear axle 13. Disconnect the plastic stops with a snap ring pliers. 7.7.1 To disassemble and assemble the rear axle (LC 247Li and LC 247iX) To remove and 1. Remove the rear wheels. Refer to attach the wheels on page 22 .
  • Page 27: Motor

    7.8 Motor 4. Release the spring with a spring pull tool. Use a hand to hold the product. Hold the product with one hand. With your other hand, pull the tool quickly and 7.8.1 To disassemble and assemble the motor with force to release the spring.
  • Page 28 Disconnect the transmission cable. Disconnect the 5. Remove the 12 screws and lift the motor cover. cables from the top of the battery holder. a) On LC 347VLi, LC 247Li, LC 247iX and LC 347iVX: b) On LC 353iVX: 28 - Repair instructions...
  • Page 29 9. Remove the motor control box. The illustration shows LC 247Li. 11. Remove the motor. a) On LC 347VLi, LC 247Li, LC 247iX and LC 347iVX: Remove the 4 bolts. Lift the motor. 361 - 001 - Repair instructions - 29...
  • Page 30 14. Remove the 4 cables on the safety switch. Remove the screw adjacent to the safety switch. 12. Push the release buttons to loosen the battery holder. The illustration shows LC 247Li. 30 - Repair instructions 361 - 001 -...
  • Page 31 15. Remove the screws. Remove the battery 17. Remove the screws. Remove the side covers. connection. 16. On LC 353iVX: Remove the 2 screws. Remove the fan. 361 - 001 - Repair instructions - 31...
  • Page 32: Safety Key Switch

    18. Remove the screws. Remove the cover. 4. Remove the 4 cables from the safety switch. 5. Remove the screw and washer. 6. Remove the safety switch. 7.9.2 To install the safety key switch 1. Put a new safety switch in the correct position as shown in the illustration.
  • Page 33: Control Panel

    4. Disconnect the control panel cable (E) from the circuit board (F). 7.10.1 To disassemble and assemble the control panel on LC 347VLi and LC 247Li 1. Remove the 4 screws. 2. Disconnect the control panel cable from the circuit board.
  • Page 34: Start Inhibitor

    7.11 Start inhibitor 4. Remove the right side of the start inhibitor. 7.11.1 To remove and install the start inhibitor 1. Remove the 4 screws and remove the cover on the left side of the start inhibitor. Pull the cables out of the start inhibitor.
  • Page 35: Troubleshooting

    8 Troubleshooting 8.1 Troubleshooting schedule Action Problem Possible cause Step Troubleshoot The product does not The battery is miss- Make sure the battery is installed Install a battery. activate. ing. correctly. The battery is defec- Press the button on the battery Replace the battery.
  • Page 36 Action Problem Possible cause Step Troubleshoot The product does not Warning indicates 2: Make sure that the blade motor Connect correctly or re- start, the warning in- Cutting motor phase is installed correctly and the place the motor if defective. dicator flashes.
  • Page 37 Action Problem Possible cause Step Troubleshoot The products stops Warning indicates 3: Operate the product without put- The product stops if the when it is operated, Cutting motor over- ting a load on the blade. load is more than 30A. the warning indicator current alarm.
  • Page 38: To Use The Common Service Tool (Cst)

    6. On the computer, select the model type of the connected product. The CST transmits data from Husqvarna products and the batteries to a computer (not included). There is a 7. On the computer, select the battery slot that is diagnostic tool list and a list of saved error codes.
  • Page 39: Wiring Diagram

    9 Wiring diagram 9.1 Wiring diagram for LC 247Li, LC 247iX, LC 347VLi and LC 347iVX Drive Cutting Control Motor Motor Panel (Only LC 347VLi and LC 347iVX) Brown Blue Yellow Main controller Green Black Motor control White Purple Drive...
  • Page 40: Wiring Diagram For Lc 353Ivx

    9.2 Wiring diagram for LC 353iVX Drive Cutting Motor Motor Control Panel Brown Blue Yellow Green Main controller Black Motor control White Purple Drive Cutting Motor ON/OFF switch ON/OFF switch Power switch Board 35A/42V Black Black switch Battery 1 Battery 2 40 - Wiring diagram 361 - 001 -...
  • Page 41: Technical Data

    20-75 mm 20-75 mm Cutting width, cm Bagger capacity, litre For best results and performance the Husqvarna battery BLi200 is recommended. Noise emissions in the environment measured as sound power (L ) in conformity with EC directive 2000/14/EC. Reported data for noise pressure level has a typical statistical dispersion (standard deviation) of 1.2 dB (A).
  • Page 42: Technical Data Lc 247Ix, Lc 347Ivx And Lc 353Ivx

    Husqvarna Battery Series Series Series Battery runtime Battery runtime, min, (free run) with SavE ac- tivated, with one Husqvarna 5.2 Ah battery (Bli200). Battery runtime, min, (free run) with standard mode activated, with one Husqvarna 5.2 Ah battery (Bli200). Noise emissions...
  • Page 43: Registered Trademarks

    ® word mark and logos are registered trademarks owned by and any use of such marks by Husqvarna is under license. Reported data for vibration level has a typical statistical dispersion (standard deviation) of 0.2 m/s . Vibration standard EN 60335-2-77:2017 chapter 20.105...
  • Page 44 115 98 55-26 2019-02-20...
