KIT COMPONENTS
• A) Mirror with mount • B) Remote • C) Accessories
A
iBEAM Vehicle Safety Systems
®
Universal
4.5 In. Monitor & DVR
Visit
iBeamUSA.com
applications
Product Features
• Forward facing and rear view recording
• G-sensor protection
• Parking Monitor options
• 1080p forward facing camera
B
C
iBEAMUSA.com
Rearview Mirror w/Integrated
for more detailed information about the product and up-to-date vehicle specific
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
TE-DVR-MM
I N S T A L L A T I O N IN S T R U C T I O N S
# i B E A M
s a f e t y
TABLE OF CONTENTS
Mirror/Monitor Installation ....................... ........... 2
Operation............................. ....................... ........... 3
Menu Options....... ................................................4-5
Specifications ......................................................6-7
TOOLS REQUIRED
• Cutting/stripping tool • Tape
• Pry tool
Attention!
When testing the aftermarket
equipment, ensure that all factory equipment
is connected before cycling the key to
ignition.
REV. 06/17/2019 INSTTE-DVR-MM
