- Page 1 TE-FTGCHD (CCD) TE-FTGC (CMOS) FORD F150 (2004-2014) Excludes 2004 Heritage model Replacement Tailgate Handle with Camera Removal and Installation Instructions Tools Needed: T30 torx bit, ratchet, 10mm socket.
- Page 2 NOTE: Some trucks will have 6 or 8 torx screws on bed liner cover (If equipped). 1. Start by lowering the tailgate and remove the (6 or 8) T30 torx screws from the bed liner, remove liner. NOTE: if your truck doesn’t have a liner please advance to the next step 2.
- Page 3 6. Now that the handle is out of the tailgate, you will have to swap the locking mechanism out of the old handle to the new one. 7. Start by removing the securing pin on the locking mechanism, and then remove mechanism from handle.
- Page 4 NOTE: If desired parking lines can be removed by attaching the green wires together. 11. Now gently reinsert new tailgate handle (avoid pinching cable running to camera). 12. Realign the handle’s post with the tailgate’s opening mechanism and reattach 10mm nuts to secure handle in tailgate.
