Summary of Contents for Avalue Technology EMX-BYTC
- Page 1 EMX-BYTC Intel® Celeron® Processor D1 J1900 Mini ITX Motherboard User’s Manual Ed – 27 March 2019 Part No. E2047EMBC02R...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
-
Page 3: Technical Support
Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification. -
Page 4: Product Warranty
Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. Warning: Battery Notice Important! To prolong battery life, please avoid adhering the battery to possible source of heat. 重要! 為了延長電池壽命，請避免電池附著在有可能出現高溫的地方 バッテリ寿命を延長するために、高温の付近にバッテリーを付着することを避けてくださ い。 4 EMX-BYTC User’s Manual... -
Page 5: Table Of Contents
2.3.18 eDP connector (EDP1) ........................27 2.3.19 LVDS connector (LVDS1) ......................28 2.3.20 TTL connector (JTTL1) ........................29 2.3.21 VGA connector (JVGA1) ....................... 29 2.3.22 Lightness control connector (JCTL) ....................30 2.3.23 LCD inverter backlight connector (INCN1) ..................30 EMX-BYTC User’s Manual... - Page 6 3.6.3.1.1 Intel IGD Configuration ......................51 3.6.3.1.2 LVDS Control ......................... 52 3.6.3.2 South Bridge .......................... 53 3.6.3.2.1 Azalia HD Audio........................54 3.6.3.2.2 USB Configuration ......................... 55 3.6.3.2.3 PCI Express Configuration ....................55 3.6.4 Security............................56 3.6.5 Boot ..............................57 6 EMX-BYTC User’s Manual...
- Page 7 4. Drivers Installation....................... 60 Install Chipset Driver ....................61 Install TXE Driver ....................62 Install VGA Driver ....................63 Install Audio Driver ....................64 Install Ethernet Driver ....................65 Install MBI Driver ..................... 66 5. Mechanical Drawing ....................67 EMX-BYTC User’s Manual...
-
Page 8: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EMX-BYTC motherboard 1 x SATA cable 1 x SATA power cable ... -
Page 9: Document Amendment History
User’s Manual 1.3 Document Amendment History Revision Date Comment March 2017 Avalue Initial Release December 2017 Avalue Increase Battery Notice March 2019 Avalue Update BIOS setup EMX-BYTC User’s Manual... -
Page 10: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up EMX-BYTC or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 11: System Specifications
When 100/1000 Mb Ethernet is connected, LED indicator remains lit. Orange: Data Transmission When the Data is transmit, the LED indicator flashes. Internal I/O Connectors 1 x 1 x 4 pin, pitch 2.54mm System fan connector with smart fan function supported Buzzer EMX-BYTC User’s Manual 11... - Page 12 1 x 1 x 3 pin, pitch 2.00mm connector for CMOS clear 1 x 1 x 4 pin, pitch 2.54mm CPU fan connector with smart fan function supported 1 x 1 x 2 pin, pitch 2.54mm JME connector for flash BIOS 12 EMX-BYTC User’s Manual...
- Page 13 0 ~ 60°C (32~140°F) Storage Temp. -40 ~ +75°C Operating 0%~90% relative humidity, non-condensing Humidity Size (L x W) 6.7" x 6.7" (170mm x 170mm) Weight 0.40 kg Note: Specifications are subject to change without notice. EMX-BYTC User’s Manual 13...
-
Page 14: Architecture Overview-Block Diagram
EMX-BYTC User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EMX-BYTC. 14 EMX-BYTC User’s Manual... -
Page 15: Hardware Configuration
User’s Manual 2. Hardware Configuration EMX-BYTC User’s Manual 15... -
Page 16: Product Overview
EMX-BYTC User’s Manual 2.1 Product Overview Note: Adjust BIOS item SATA 0 refers to SATA 2 connector on PCBA 16 EMX-BYTC User’s Manual... -
Page 17: Jumper And Connector List
3 x 1 header, pitch 2.00mm JEDP_PWR AT/ATX mode selector 3 x 1 header, pitch 2.54mm JME connector 2 x 1 header, pitch 2.54mm Connectors Label Function Note 4 x 1 wafer, pitch 2.54mm SFAN1 System fan connector EMX-BYTC User’s Manual 17... - Page 18 204-pin DDR3L SODIMM socket MSATA1 Full size mPCIe Slot MPCIE1 Mini-PCIe connector SIM1 SIM card slot 4 x 1 wafer, pitch 2.00mm LCTL Lightness control connector JTTL1 TTL connector 3 x 1 header, pitch 2.54mm LPT connector 18 EMX-BYTC User’s Manual...
-
Page 19: Setting Jumpers & Connectors
User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 LVDS Back Light power selection (JPWR_LVDS1) 3.3V* * Default 2.3.2 Clear CMOS (JBAT1) Protect* Clear CMOS * Default EMX-BYTC User’s Manual 19... -
Page 20: Serial Port 1 Pin9 Power Selector (Jc11)
EMX-BYTC User’s Manual 2.3.3 Serial port 1 pin9 power selector (JC11) +12V * Default 2.3.4 Serial port 2 pin9 power selector (JC21) +12V * Default 20 EMX-BYTC User’s Manual... -
Page 21: Serial Port 3 Rs-232/Ttl Mode Selector (Jc31/32)
User’s Manual 2.3.5 Serial port 3 RS-232/TTL mode selector (JC31/32) RS-232* (JC31) (JC32) JC31 JC32 TTL 3.3V (JC31) (JC32) * Default 2.3.6 AT/ATX mode selector (AT1) Auto on* Normal * Default EMX-BYTC User’s Manual 21... -
Page 22: Edp Power Selection (Jedp_Pwr)
EMX-BYTC User’s Manual 2.3.7 EDP power selection (JEDP_PWR) 3.3V* * Default 2.3.8 JME connector (JME) Normal* OVERRIDE * Default 22 EMX-BYTC User’s Manual... -
Page 23: Serial Port 2/3/4/5/6 Connector (Jcom2/3/4/5/6)
Serial port 2/3/4/5/6 connector (JCOM2/3/4/5/6) JCOM3 JCOM2 JCOM5 JCOM4 JCOM6 Signal PIN PIN Signal NRI_R NCTS NRTS NDSR NDTR NSOUT NSIN NDCD 2.3.10 General purpose I/O connector (GPIO1) Signal PIN PIN Signal GPIO_IN2 GPIO_OUT2 GPIO_IN1 GPIO_OUT1 EMX-BYTC User’s Manual 23... -
Page 24: Sata Power Connector (Jsata_Pwr)
EMX-BYTC User’s Manual 2.3.11 SATA Power connector (JSATA_PWR) Signal VCC12 2.3.12 Power connector (ATX1) Signal Signal AC_IN AC_IN 24 EMX-BYTC User’s Manual... -
Page 25: Usb 2.0 Connector 1 (F_Usb1)
User’s Manual 2.3.13 USB 2.0 connector 1 (F_USB1) Signal Signal USBH_TP5 USBH_TP6 USBH_TN5 USBH_TN6 USB2_PWR USB2_PWR 2.3.14 USB 2.0 connector 2 (F_USB2) Signal Signal USBH_TP7 USBH_TP8 USBH_TN7 USBH_TN8 USB2_PWR USB2_PWR EMX-BYTC User’s Manual 25... -
Page 26: Front Audio Connector (F_Audio1)
EMX-BYTC User’s Manual 2.3.15 Front Audio connector (F_AUDIO1) Signal PIN PIN Signal SENSE_B LINE2_L SENSE_B LINE2_R MIC2_R MIC2_L 2.3.16 SYS fan connector (SFAN1) Signal VCC12 FAN_TAC1 FAN_CTL1 26 EMX-BYTC User’s Manual... -
Page 27: Front Panel Connector (Fpanel1)
PIN PIN Signal RSTBTN_N PBTNJ_SIO SATA_LED_N GND VCC 2.3.18 eDP connector (EDP1) Signal PIN PIN Signal VCC_EDP VCC_EDP DDI0_TX0_DN DDI0_TX0_DP DDI0_TX1_DN DDI0_TX1_DP DDI0_TX2_DN DDI0_TX2_DP DDI0_TX3_DN DDI0_TX3_DP EDP_AUXN EDP_AUXP DDI0_AUX_DN DDI0_AUX_DP HPD_EDP EDP_BKLT_EN 25 EDP_BKLT_CTL BLPWR BLPWR EMX-BYTC User’s Manual 27... -
Page 28: Lvds Connector (Lvds1)
CHLVDS_DATA7P 30 29 CHLVDS_DATA7N CHLVDS_CLK2P CHLVDS_CLK2N CHLVDS_DATA6P 24 23 CHLVDS_DATA6N CHLVDS_DATA5P 22 21 CHLVDS_DATA5N CHLVDS_DATA4P 20 19 CHLVDS_DATA4N CHLVDS_DATA3P 18 17 CHLVDS_DATA3N CHLVDS_CLK1P CHLVDS_CLK1N CHLVDS_DATA2P 12 11 CHLVDS_DATA2N CHLVDS_DATA1P 10 CHLVDS_DATA1N CHLVDS_DATA0P CHLVDS_DATA0N CHVDD_PANEL CHVDD_PANEL CHVDD_PANEL 28 EMX-BYTC User’s Manual... -
Page 29: Ttl Connector (Jttl1)
User’s Manual 2.3.20 TTL connector (JTTL1) Signal TTL_TX TTL_RX 2.3.21 VGA connector (JVGA1) Signal HVSYNC HHSYNC RED_H GREEN_H BLUE_H DDC_DATA_H DDC_CLK_H EMX-BYTC User’s Manual 29... -
Page 30: Lightness Control Connector (Jctl)
EMX-BYTC User’s Manual 2.3.22 Lightness control connector (JCTL) Signal CH_PWRDN CH_BLDN CH_BLUP 2.3.23 LCD inverter backlight connector (INCN1) Signal BKLTCTL CHENBKL VCC12 VCC12 30 EMX-BYTC User’s Manual... -
Page 31: Bios Setup
User’s Manual 3.BIOS Setup EMX-BYTC User’s Manual 31... -
Page 32: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 32 EMX-BYTC User’s Manual... -
Page 33: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. EMX-BYTC User’s Manual 33... -
Page 34: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 34 EMX-BYTC User’s Manual... -
Page 35: Bios Setup
<Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. EMX-BYTC User’s Manual 35... -
Page 36: System Language
Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 36 EMX-BYTC User’s Manual... -
Page 37: Acpi Settings
Enable Hibernation Enabled[Default], This option may be not effective with some OS. Select the highest ACPI sleep state Suspend Disabled, ACPI Sleep State the system will enter when the S3 (Suspend to RAM)[Default] SUSPEDN button is pressed. EMX-BYTC User’s Manual 37... -
Page 38: It8786E Super Io Configuration
Specify what state to go to when Restore AC Power Loss By IO Power On power is re-applied after a power Last State failure (G3 state). Disabled[Default] Watch dog Controller Second Allow select second or minute unit. Minute 38 EMX-BYTC User’s Manual... -
Page 39: Serial Port 1 Configuration
User’s Manual 3.6.2.2.1 Serial Port 1 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.2.2 Serial Port 2 Configuration EMX-BYTC User’s Manual 39... -
Page 40: Serial Port 3 Configuration
Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.2.3 Serial Port 3 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.2.4 Serial Port 4 Configuration 40 EMX-BYTC User’s Manual... -
Page 41: Serial Port 5 Configuration
Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.2.5 Serial Port 5 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.2.6 Serial Port 6 Configuration EMX-BYTC User’s Manual 41... -
Page 42: Parallel Port Configuration
3.6.2.2.7 Parallel Port Configuration Item Option Description Enabled[Default], Enable or Disable Parallel Port Parallel Port Disabled (LPT/LPTE). Standard Parallel Port mode(SPP) [Default] EPP Mode Device Mode Change the Printer Port mode. ECP Mode EPP Mode & ECP Mode 42 EMX-BYTC User’s Manual... -
Page 43: It8786E Hardware Monitor
Enable or disable System wake on alarm event. Select Fixed Time, system will wake on Disabled[Default], Restore on RTC Alarm the hr::min::sec specified. Select Dynamic Enabled Time, System will wake on the current time + Increase minute(s). EMX-BYTC User’s Manual 43... -
Page 44: Cpu Configuration
Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3.) When enabled, a VMM can utilize the Disabled, Intel Virtualization Technology additional hardware capabilities provided by Enabled[Default] Virtualization Technology. Disabled[Default], Power Technology Energy Efficient Enable the power management features. Custom 44 EMX-BYTC User’s Manual... -
Page 45: Socket 0 Cpu Information
User’s Manual 3.6.2.5.1 Socket 0 CPU Information 3.6.2.6 PPM Configuration Item Options Description Disabled, EIST Enable/Disable Intel SpeedStep. Enabled[Default] Disabled[Default], CPU C state Report Enable/Disable CPU C state report to OS. Enabled EMX-BYTC User’s Manual 45... -
Page 46: Ide Configuration
SATA Speed Support Gen1 or Gen2. Gen2[Default] Port0 ODD SATA ODD Port Port1 ODD SATA ODD is Port0 or Port1. No ODD[Default] IDE Mode SATA Mode Select IDE/AHCI. AHCI Mode[Default] Enabled[Default] Serial-ATA Port 0/1 Enable/Disable Serial ATA Port0/1. Disabled, 46 EMX-BYTC User’s Manual... -
Page 47: Network Stack Configuration
User’s Manual 3.6.2.8 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] 3.6.2.9 CSM Configuration Item Options Description CSM Support Enabled[Default] Enable/Disable CSM Support. EMX-BYTC User’s Manual 47... -
Page 48: Usb Configuration
Network, Storage, or Video. 3.6.2.10 USB Configuration The USB Configuration menu helps read USB information and configures USB settings. Item Options Description XHCI Hand-off Enabled[Default] This is a workaround for OSew without XHCI 48 EMX-BYTC User’s Manual... - Page 49 Optical drives are emulated as ‘CDROM’, JetFlashTranscend 8GB 1100 Forced FDD Hard Disk drives with no media will be emulated according CD-ROM to a drive type. 3.6.2.11 Realtek PCIe GBE Family Controller (MAC:00:04:5F:A2:AC:E4) EMX-BYTC User’s Manual 49...
-
Page 50: Chipset
EMX-BYTC User’s Manual 3.6.2.12 Realtek PCIe GBE Family Controller (MAC:00:04:5F:A2:AC:E5) 3.6.3 Chipset 50 EMX-BYTC User’s Manual... -
Page 51: North Bridge
User’s Manual 3.6.3.1 North Bridge Item Option Description Dynamic[Default] Max TOLUD 2 GB Maximum Value of TOLUD. 2.25 GB 3.6.3.1.1 Intel IGD Configuration EMX-BYTC User’s Manual 51... -
Page 52: Lvds Control
Select the Aperture Size. 256MB[Default] 3.6.3.1.2 LVDS Control Item Option Description Disabled LVDS Controller(ch7511) LVDS Controller(ch7511). Enabled[Default] 1024x600 18/1 1024x768 18/1 800x600 18/1 LVDS Resolution Type 1280x768 18/1 LVDS Resolution Type. 1920x1080 18/2 1366x768 18/1 800x600 24/1 52 EMX-BYTC User’s Manual... -
Page 53: South Bridge
1280x800 24/1 1600x900 24/2 1366x768 24/1 1280x800 18/1 1280x1024 24/2 1440x900 24/2 1920x1080 24/2 3.6.3.2 South Bridge Item Option Description Disable[Default] Controls the execution of UEFI and Legacy Realtek Lan PXE Oprom Legacy only PXE OpROM. EMX-BYTC User’s Manual 53... -
Page 54: Azalia Hd Audio
Disabled = Azalia will be unconditionally Enabled[Default], Audio Controller disabled. Enabled = Azalia will be Disabled unconditionally Enabled. Auto = Azalia will be enabled if present disabled otherwise. Enabled[Default], HDMI Port B Enable/Disable HDMI Port B. Disabled 54 EMX-BYTC User’s Manual... -
Page 55: Usb Configuration
User’s Manual 3.6.3.2.2 USB Configuration Item Option Description Windows 8.X OS Selection Android OS Selection. Windows 7[Default] 3.6.3.2.3 PCI Express Configuration EMX-BYTC User’s Manual 55... -
Page 56: Security
Enabled[Default], Enable or Disable the PCI Express Port 2 in PCI Express Port 2(MPCIE1) Disabled the Chipset. Auto[Default] Speed Gen 2 Configure PCIe Port Speed. Gen 1 3.6.4 Security Administrator Password Set setup Administrator Password 56 EMX-BYTC User’s Manual... -
Page 57: Boot
Enables or disables boot with Disabled[Default] initialization of a minimal set of devices Fast Boot Enabled required to launch active boot option. Has no effect for BBS boot options. Boot Option #1/2 Set the system boot order. EMX-BYTC User’s Manual 57... -
Page 58: Save And Exit
EMX-BYTC User’s Manual 3.6.6 Save and exit 3.6.6.1 Save Changes and Reset Reset the system after saving the changes. 3.6.6.2 Discard Changes and Reset Reset system setup without saving any changes. 58 EMX-BYTC User’s Manual... -
Page 59: Restore Defaults
User’s Manual 3.6.6.3 Restore Defaults Restore/Load Default values for all the setup options. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shell.efi) from one of the available filesystem devices. EMX-BYTC User’s Manual 59... -
Page 60: Drivers Installation
EMX-BYTC User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 60 EMX-BYTC User’s Manual... -
Page 61: Install Chipset Driver
Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Install. Step1. Click Next. Step 4. Click Finish to complete setup. Step 2. Click Accept. EMX-BYTC User’s Manual 61... -
Page 62: Install Txe Driver
If the warning message appears while the installation process, click Continue to go on. Step 3. Click Next to continue installation. Step 4. Click Finish to complete setup. Step1. Click Next to start installation. Step 2. Click Next. 62 EMX-BYTC User’s Manual... -
Page 63: Install Vga Driver
Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 5. Click Finish to complete setup. Step 2. Click Yes to accept license agreement. EMX-BYTC User’s Manual 63... -
Page 64: Install Audio Driver
Index.htm and choose the product from the menu left. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 1. Click Next to continue setup. Step 2. Click Finish to complete the setup. 64 EMX-BYTC User’s Manual... -
Page 65: Install Ethernet Driver
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Finish to complete the setup. Step 1. Click Next. Step 2. Click Install. EMX-BYTC User’s Manual 65... -
Page 66: Install Mbi Driver
If the warning message appears while the installation process, click Continue to go on. Step 3. Click Next to continue installation. Step 4. Click Finish to complete setup. Step1. Click Next to start installation. Step 2. Click Yes. 66 EMX-BYTC User’s Manual... -
Page 67: Mechanical Drawing
User’s Manual 5. Mechanical Drawing EMX-BYTC User’s Manual 67... - Page 68 EMX-BYTC User’s Manual Unit: mm 68 EMX-BYTC User’s Manual...
