• E nsure adequate air return/discharge into/from the room in compliance with existing
regulations in order to ensure proper device operation.
• I f the environment in which the product is installed also houses a fuel-operating device
(water heater, methane stove etc., that is not a "sealed chamber" type), it is essential
to ensure adequate air intake, to ensure good combustion and proper equipment
operation.
INTRODUCTION
Quantum HR is a single alternate flow decentralized (single point) residential heat recovery
unit, also called «push&pull» unit, designed to ensure adequate ventilation in enclosed
environments without energy losses.
It is recommended that two units are installed in pair: when one unit is pulling, the other
is pushing.
Pair of units can be installed in the same room or in different rooms (i.e. livingroom and
bedroom). The unit is suitable for installation on an outside wall.
The unit should operate continuously, and only stopped for maintenance or
service. When heat exchange is not useful (for example in mid-seasons when
indoor and outdoor temperatures are similar), or when heat exchange is not
recommended (for example with the option "summer free cooling"), or it is
requested to increase the acoustic comfort, or in case of extreme weather
conditions (for example with strong wind or exceptionally rigid temperatures),
it is recommended to set the unit in extract only mode (eventually at minimum

TECHNICAL SPECIFICATIONS

• I nner ventilation unit material: high quality, impact and UV-resistant ABS colour RAL 9010.
• D esign front cover removable for cleaning without the use of tools.
• E asy maintenance installation plate, for easy access to the heat exchanger from inside
the room.
• A nti-dust filter, easily removable for washing by the user without tools.
• R egenerative honeycombs ceramic heat exchanger.
• E xternal grille in high quality, impact and UV-resistant ABS colour RAL 9010 (STANDARD
version) or external hood in aluminium, painted in white RAL 9010, acoustically lined
(PRO version).
• H igh efficiency aerodynamic fan with "winglet" blades to optimise quietness and
efficiency.
• S ingle phase EC reversible Brushless motor with integral thermal protection.
• M otor mounted on high quality ball bearings.
• T he unit is double insulated: no earth connection is required.
• T rickle speed selectable.
• B oost mode.
• F ree-cooling (Bypass) mode.
• I PX4 degree of protection.
• P ower supply 220V to 240V~ 50Hz.
VERSIONS
STANDARD
External grille in high quality, impact and UV-resistant ABS colour RAL 9010.
PRO
External hood in aluminium, painted in white (RAL 9010), acoustically lined.
speed) and NOT to switch it off.
Model Airflow m
Quantum HR 100 10/15/25
Quantum HR 150 20/40/60
Quantum HR 100 PRO 10/15/25
Quantum HR 150 PRO 20/40/60
/h Power W Weight Kg
3
1,2/1,7/2,6 2
1,4/2,3/3,8 4,2
1,2/1,7/2,6 2,2
1,4/2,3/3,8 4,5
5
