Your kit contains the following parts. Please check your kit for any missing or damaged parts before starting construction.
Wood Bag:
1 LC-501-01
3/32"x4"x24" Laser Cut Balsa Sheet
1 LC-501-03
3/32"x4"x24" Laser Cut Balsa Sheet
1 LC-501-06
3/32"x3"x12" Laser Cut Balsa Sheet
1 LC-501-08
1/32"x2.4"x4.5" Laser Cut Birch Ply
2 Landing Gear Block
3/8"x1/2"x25/16" Grooved Hardwood Block
Wood (Loose in Box):
1 LC-501-05
3mmx6"x9" Laser Cut Poplar Ply
2 Main Spar
3/16"sq. x36" Balsa Strip
1 Trailing Edge
5/16"x1"x 6" Tapered Balsa Trailing Edge
1 3/32"x1/4" Strip
3/32"x1/4"x18" Balsa Strip
Misc. Parts Loose in Box:
2 Main Landing Gear
1 Pushrod
1/16"x18" Wire Pushrod "Z" Bend One End
1 Canopy
1 Plan Sheet #2
1 Instruction Book
Hardware Bag:
1 Control Horn
Small Nylon Control Horn
2 Torque Rod Bearing
1/16" ID. x4" Nylon Tube
2 Aileron Connectors
Molded Nylon Fitting
2 Wing Dowels
3/16"x3 1/2" Birch Dowels
1 Rudder Filler Block
1/4"x3/4"x2" Balsa Block ( makes 2 parts)
4 Landing Gear Attach
#4 x1/2" Sheet Metal Screws
Screws
COMPLETE KIT PARTS LIST
1 LC-501-02
1 LC-501-04
1 LC-501-07
2 Wing Tip
1 Leading Edge
2 Leading Edge Strips
1 1/16" Balsa Sheet
2 1/16" Bent Aileron
Torque Rod
1 Cowl
1 Plan Sheet #1
1 Decal Sheet
2 Horn Screw
1 Tail Wheel Wire
1 Elevator Joiner
3 Cowl Attach Screws
3 Cowl Attach Blocks
3/32"x4"x24" Laser Cut Balsa Sheet
3/32"x4"x24" Laser Cut Balsa Sheet
3/32"x3"x3" Laser Cut Balsa Sheet
3/4"x3/4"x4" Balsa Block
1/4"sq. x36" Balsa Strip
3/32"sq. x36" Balsa Strip
1/16"x3"x 6" Balsa Sheet
2-56x3/8" Machine Screw
1/16" x 3" Music Wire
1/8" x 3" Birch Dowel
#2 x1/2" Sheet Metal Screws
3/8"x3/8"x3/8" Hard Wood Block
Advertisement
Table of Contents
Related Manuals for SIG HRR501
Summary of Contents for SIG HRR501
- Page 1 Your kit contains the following parts. Please check your kit for any missing or damaged parts before starting construction. COMPLETE KIT PARTS LIST Wood Bag: 1 LC-501-01 3/32"x4"x24" Laser Cut Balsa Sheet 1 LC-501-02 3/32"x4"x24" Laser Cut Balsa Sheet 1 LC-501-03 3/32"x4"x24"...
- Page 2 The first thing that you need to do is to identify and mark the part numbers on the laser cut parts using the drawings on the following pages as a guide. It is possible that several of the laser cut parts may not be completely cut through. If this is the case you can free the part from the sheet quickly using an X-acto knife.
-
Page 3: Building The Tail Surfaces
Sullivan loz. #SS-1 or 20z. #SS-2 1 1/2-A Fuel Line Sig #SH-288 or Du-Bro #221 3 Servo Connectors Sig #SH-736 or Du-Bro #121 (5 Reqd. if using Rudder and Throttle) 1 Yellow Covering Material 1 Roll Top Flite Monokote, Cub Yellow #TOPQ0220... - Page 4 10. Place the opposite fuselage side onto the F-3 and F-4 formers and glue into position. The formers should be 90 degrees to the fuselage side. 11. Place the fuselage top (F-8) ·into position. Working from F-4 forward, glue F-8 into position. 12.
-
Page 5: Building The Wing
Building the Wing Center Section: 32. Cut the lower 3/16" sq. main spar from one of the 36" pieces and pin it to the plan. 33. Cut a piece of trailing edge to length and pin it into position on the plan. 34. - Page 6 53. Sand the leading edge of the wing round and sand the wing smooth all over. 54. Measure and draw a line on the top of the trailing edge, 1/4" back from the forward top comer. Use a straight edge to guide your knife while you cut the trailing edge from the wing.
-
Page 7: Final Assembly
71. Attach the motor mount to the firewall and then install the engine on the mount. When using the Norvel engine, the muffler is positioned so the exhaust is in the front. 72. Mark and dnll the holes in the firewall for the fuel and vent hnes and the throttle cable. 73. - Page 8 LIMIT OF LIABILITY: In use of our products, Sig Mfg. Co.'s only obligation shall be to replace such quantity of the product proven to be defective. User shall determine the suitability of the product for his or her intended use and shall assume all risk and liability in connection...
