EtherWAN EX42300 series Quick Start Manual

EX42300 series
This quick start guide describes how to install and use the Hardened PoE Ethernet
Switch. Capable of operating at temperature extremes of -40°C to +75°C, this is the
Switch of choice for harsh environments constrained by space.

Physical Description

The Port Status LEDs
Hardened PoE Ethernet Switch
LED State Indication
Steady Power on.
Power
Off Power off.
(Green)
Steady Relay starts alarm.
Fault
Off Relay non-alarm.
(Red)
10/100TX Ports
A valid network connection
Steady
established.
Link/Act
Transmitting or receiving data.
(Green) Blinking
Act stands for Activity.
Off No link.
Steady Powered Device is connected.
PoE
Off Powered Device is disconnected.
(Amber)
Blinking While Powered Device over 30W.
Gigabit Port
A valid network connection
Steady
established.
Link/Act
Transmitting or receiving data.
(Amber) Blinking
Act stands for Activity.
Off No link.
The Terminal Block and Power Inputs
Power Input Assignment
Power1
Power2
Relay Output Rating
DC Terminal Block Power Input: The DC Terminal Block power input can be used to
power up this Switch.

DIP Switch Settings

DIP No.
1
2
3
4
5
6 (Only for EX42315)
7
8
1
www.etherwan.com
＋
24/48VDC
－
Power Ground
＋ Terminal Block
24/48VDC
－
Power Ground
Earth Ground
1A @ 250VAC
On Off
Port 1 Alarm Enable. Port 1 Alarm Disable.
Port 2 Alarm Enable. Port 2 Alarm Disable.
Port 3 Alarm Enable. Port 3 Alarm Disable.
Port 4 Alarm Enable. Port 4 Alarm Disable.
Port 5 Alarm Enable. Port 5 Alarm Disable.
Port 6 Alarm Enable. Port 6 Alarm Disable.
Broadcast Storm Enable. Broadcast Storm Disable.
Jumbo Frame Enable. Jumbo Frame Disable.
W70G-EX42300Q2
