Page 1: Installation Instructions
Sierra , Rivers Edge, Grandstone & San J u an Table Installation Instructions P a g e www.NorthlineExpress.com NorthlineExpress.com Toll-Free 1-877-734-2458... -
Page 2: Table Of Contents
Contents Contents……………………………………………………..2 Required Tools…………………………………………..3 Placing the Table………………………………………4 Gas Connection………………………….…………….5 Igniter Installation…………….………………………...6 Placing the Top…………………………………………..7 Burner Installation……………………………………….8 Locating Propane tank……………………………..9 Door Installation…………………………………………...10 P a g e www.NorthlineExpress.com NorthlineExpress.com Toll-Free 1-877-734-2458... -
Page 3: Required Tools
One (1) AAA Battery (not included) Required for igniter installation for Crystal Fire burners. It is recommended that a minimum of two people assemble and install the Sierra and San Juan Coffee Tables. P a g e www.NorthlineExpress.com NorthlineExpress.com Toll-Free 1-877-734-2458... -
Page 4: Placing The Table
Placing the Sierra/San Juan table 1. Remove access door 2. Remove the base from the box 3. Move the base without door to desired location and set into place. 4. When locating your coffee table, refer to the Crystal Fire manual and maintain clearance to combustibles. -
Page 5: Gas Connection
Gas Connection 1. Connect the incoming gas hose to the valve. It is not recommended to use Teflon tape or pipe dope on the connection to the valve with flare fittings. LPG installations use the hose and regulator provided with the burner. ... -
Page 6: Igniter Installation
Igniter Installation 1. Make sure the valve in in the OFF position 2. Install the igniter by unscrewing the top cap and hex nut counter-clockwise. Once the top cap and nut are separate, place the box portion on the inside of the unit with the threaded body through the hole. -
Page 7: Placing The Top
Placing the top 1. With the help of at least one other person, remove Super Cast concrete top from packaging and gently lower on to your fire pit table base. Construction adhesive or silicone may be used on the top of the base for a more permanent placement. -
Page 8: Burner Installation
Burner Installation Before Completing this step, read and understand the Crystal Fire owner’s manual. Lower burner on to base Electrode wire Connect gas line and electrode wire P a g e www.NorthlineExpress.com NorthlineExpress.com Toll-Free 1-877-734-2458... -
Page 9: Locating Propane Tank
Locating your Tank 1. Your tank should be positioned so that the fuel can be shut off after each use. 2. Slide the tank into the framework past the line shown below. This is to allow the door to close completely. 3. -
Page 10: Door Installation
Door Installation Door support Set door on supports and close. Magnet will hold door in closed position. IMPORTANT Please consult your Crystal Fire instruction manual for detailed instructions and important information related to hooking up your CF- 20 burner, including safety information, proper tightening of connections with two wrenches and full burner setup and lighting instructions. - Page 11 ENTIONALLY LEFT AWESOME. Warranty: Fire pit tables are covered under a 1- year manufacturer’s warranty. Please visit http://www.outdoorrooms.com/warranty-form to register your product. 2015 Silver Bell Road • Suite 195 • Toll Free: 1-866-303-4028 11 | P a g e www.NorthlineExpress.com NorthlineExpress.com Toll-Free 1-877-734-2458...
