USER MANUAL FOR: CFP20, BI16, CFP30, BI28, CFP2424, BI1919, CFP1224, BI719, CFP1242, BI737, CFP1264, BI757,
CFP1272, BI766, CFP1284, BI778, CFP1296, BI790, CFP12108, BI7102, CFP12120, BI7114 AND CUSTOM LINEAR BURNERS
• Important operating instructions included.
• Read, understand, and follow these
instructions for safe installation and operation.
WARNING
!
FOR OUTDOOR USE ONLY.
Installation and service must be performed by a
qualified installer, service agency, or the gas
DANGER
IF THE INFORMATION IN THIS INSTRUCTION MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE.
!
!
supplier.
!
CAUTION
INSTALLER: Leave manual with the appliance.
CONSUMER: Retain this manual for future
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, leave the area immediately.
• After leaving the area, call your gas supplier
or fire department.
Failure to follow these instructions could result
in fire or explosion, which could cause property
damage, personal injury or death.
Do not store or use gasoline, or other
flammable vapors and liquids, in the vicinity of
this or any other appliance.
A propane cylinder not connected for use shall
not be stored in the vicinity of this or any other
appliance.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space
such as a camper, tent, car or home.
WARNING
www.outdoorrooms.com
!
reference.
DANGER
!
IF YOU SMELL GAS:
WARNING
!
which has no odor.
!
!
!
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Outdoor GreatRoom Company Crystal Fire Plus CFP20
Summary of Contents for Outdoor GreatRoom Company Crystal Fire Plus CFP20
- Page 1 USER MANUAL FOR: CFP20, BI16, CFP30, BI28, CFP2424, BI1919, CFP1224, BI719, CFP1242, BI737, CFP1264, BI757, CFP1272, BI766, CFP1284, BI778, CFP1296, BI790, CFP12108, BI7102, CFP12120, BI7114 AND CUSTOM LINEAR BURNERS CAUTION • Important operating instructions included. INSTALLER: Leave manual with the appliance. CONSUMER: Retain this manual for future •...
- Page 2 DANGER: FLAMMABLE GAS UNDER PRESSURE. LEAKING LP-GAS MAY CAUSE A FIRE OR EXPLOSION IF IGNITED CAUSING SERIOUS BODILY INJURY OR DEATH. CONTACT LP GAS SUPPLIER FOR REPAIRS, OR DISPOSAL OF A CYLINDER OR UNUSED LP-GAS. WARNING: FOR OUTDOOR USE ONLY.* DO NOT USE OR STORE CYLINDER IN A BUILDING, GARAGE, OR ENCLOSED AREA.
- Page 3 Report damaged parts to your dealer. Installation and repair should be performed only by a qualified WARNING service person. More frequent The Outdoor GreatRoom Company , LLC cleaning and maintenance may disclaims any responsibility for, and the be required as necessary. It is...
-
Page 4: Table Of Contents
TABLE OF CONTENTS 1. Appliance Information Appliance Certification Specifications 2. Getting Started Included Items Tools and Supplies Required Inspect the Appliance and Components 3. Appliance Clearance Requirments Surrounding Clearances Enclosure Clearances for CFP Models Enclosure Clearances for BI Models 4. Enclosure Design Requirements Self-Contained Propane Cylinder Installations Hard-Piped Propane Installations Hard-Piped Natural Gas Installations... - Page 5 11. Appliance Information (DSI Burners) Appliance Certification Specifications 12. Getting Started (DSI Burners) Included Items Tools and Supplies Required Inspect the Appliance and Components 13. Appliance Clearance Requirments (DSI Burners) Surrounding Clearances Enclosure Clearances for CFP Models with DSI Enclosure Clearances for BI Models with DSI 14.
- Page 6 APPLIANCE INFORMATION A. APPLIANCE B. SPECIFICATIONS CERTIFICATION MODEL ORIFICE SIZE STANDARD INPUT RATE ® MODEL: ALL CRYSTAL FIRE NATURAL PLUS BURNERS & BURNER PROPANE PROPANE NATURAL GAS INSERTS CFP20 #43 (Burner) #30 (Burner) Low: 25K BTU/hr. Low: 25.5K BTU/hr. TESTING AGENCY: Underwriters BI16 (7.32 kW) (7.47 kW)
- Page 7 MODEL ORIFICE SIZE MAXIMUM INPUT RATE PROPANE NATURAL GAS PROPANE NATURAL GAS CFP20* #36 (Burner) #21 (Burner) Low: 26K BTU/hr. (7.62 kW) Low: 25.5K BTU/hr. (7.47 kW) BI16* #52 (Valve) #43 (Valve) High: 73.5K BTU/hr. (21.5 kW) High 77.5K BTU/hr. (22.12 kW) CFP1224* #36 (Burner) #21 (Burner)
-
Page 8: Getting Started
GETTING STARTED A. INCLUDED ITEMS 1. Crystal Fire® Plus Burner SEE DETAIL A 2. Crystal Fire® Plus Instruction Manual 3. UL Rating Label (attached to burner) DETAIL A CFP20 CFP30 CFP2424 CFP1224 CFP1242 CFP1264 Included Item BI16 BI28 BI1919 BI719 BI737 BI757 10’... -
Page 9: Tools And Supplies Required
B. TOOLS AND SUPPLIES REQUIRED Work Gloves Safety Glasses Utility Knife (for opening packaging) (2X) Adjustable Wrenches 11mm Wrench (for NG conversion only) 10mm Wrench Phillips Screwdriver Flat-Blade Screwdriver (for NG conversion only) Corrosion-free Leak Test Solution (1X) AAA Battery C. -
Page 10: Appliance Clearance Requirments
APPLIANCE CLEARANCE REQUIREMENTS A. SURROUNDING CLEARANCES WARNING WARNING FIRE RISK FOR OUTDOOR USE ONLY Follow all minimum clearance requirements. Failure to provide adequate clearance to What qualifies an area as an outdoor space? combustible materials can result in property To qualify as an outdoor space, the area in damage or loss of life. -
Page 11: Enclosure Clearances For Cfp Models
B. ENCLOSURE CLEARANCES FOR CFP MODELS WARNING Follow all minimum clearance requirements. Failure to provide adequate clearance to combustible materials can result in property damage or loss of life. Required Clearances to Combustibles LINEAR MODELS CFP1224 CFP1242 CFP1264 CFP2424 4 in. 4 in. - Page 12 C. ENCLOSURE CLEARANCES FOR BI MODELS WARNING Follow all minimum clearance requirements. Failure to provide adequate clearance to combustible materials can result in property damage or loss of life. Required Clearances to Combustibles LINEAR MODELS BI719 BI737 BI757 BI1919 7 in. 7 in.
-
Page 13: Enclosure Design Requirements
ENCLOSURE DESIGN REQUIREMENTS A. SELF-CONTAINED PROPANE CYLINDER INSTALLATIONS The Outdoor GreatRoom Company has vent blocks available for DIY landscape block projects as well as vent plates for other enclosures. See reference materials for more information. OPENINGS ARE SHOWN AS 5" X 2"... -
Page 14: Hard-Piped Propane Installations
B. HARD-PIPED PROPANE INSTALLATIONS The Outdoor GreatRoom Company has vent blocks available for DIY landscape block projects as well as vent plates for other enclosures. See reference materials for more information. OPENINGS ARE SHOWN AS 5" X 2" RECTANGLES. 5.00 MAXIMUM... - Page 15 C. HARD-PIPED NATURAL GAS INSTALLATIONS The Outdoor GreatRoom Company has vent blocks available for DIY landscape block projects as well as vent plates for other enclosures. See reference materials for more information. OPENINGS ARE SHOWN AS 5" X 2" RECTANGLES.
-
Page 16: Gas Setup And Information
GAS SETUP AND INFORMATION • Pressure requirements for the appliance are WARNING: shown in the table below. Pressure readings must FIRE AND EXPLOSION RISK: be attained WHILE THIS APPLIANCE AND ALL OTHER GAS APPLIANCES ARE IN OPERATION. VERIFY INLET PRESSURES •... -
Page 17: Leak Check And Line Purge
E. ADDITIONAL GAS SUPPLY D. LEAK CHECK AND LINE PURGE INFORMATION Once the gas piping system is in place, all fittings and connections need to be checked for For propane installations using a non-disposable, leaks. self-contained propane supply system (20 lb. propane tank and the manufacturer supplied Use a commercially-available, non-corrosive regulator hose):... -
Page 18: Burner Installation
Other media options apart from the supplied clear glass gems can be used in Crystal Fire® Plus burners, but they should be supplied by the Outdoor GreatRoom Company . This ensures that the proper amount of media is used and that the media is approved for use in gas appliances. - Page 19 Secure control valve to control panel with two (2) supplied Phillips head screws. Install control knob onto valve stem. See Image 6.4. Connect igniter and ground wire to sparker box. See Image 6.5. Both wires can connect to either connection point. The unit will operate in either configuration.
- Page 20 Press and hold the sparker button to verify LOOK FOR SPARK HERE presence of spark. Look inside ignition wind guard for visible spark. See Image 6.8. DEPRESS SPARKER BUTTON Ensure propane cylinder valve is closed. Hand-tighten propane regulator hose to (Img.
-
Page 21: Hard-Piped Propane Installations
B. HARD-PIPED PROPANE INSTALLATIONS WARNING Installation and repair should be performed only by a qualified service technician. Secure supplied control panel to enclosure with (Img. 6.12) suitable fasteners. See Image 6.12. If installing into an Outdoor GreatRoom Company fire table, a control panel will already be installed and the supplied control panel can be discarded. - Page 22 Secure control valve to control panel with two (2) supplied Phillips head screws. Install control knob onto valve stem. See Image 6.16. Connect igniter and ground wire to sparker box. See Image 6.17. Both wires can connect to either connection point. The unit will operate in either configuration.
- Page 23 Carefully place burner assembly into SPREAD MEDIA EVENLY MEDIA CAN BE PLACED ON enclosure. Evenly spread glass media over SPREAD MEDIA EVENLY MEDIA CAN BE PLACED ON ACROSS BURNER SURFACE IGNITION WIND GUARD COVER ACROSS BURNER SURFACE IGNITION WIND GUARD COVER burner surface.
-
Page 24: Hard-Piped Natural Gas Installations
C. HARD-PIPED NATURAL GAS INSTALLATIONS WARNING Installation and repair should be performed only by a qualified service technician. Secure supplied control panel to enclosure with (Img. 6.24) suitable fasteners. See Image 6.24. If installing into an Outdoor GreatRoom Company fire table, a control panel will already be installed and the supplied control panel can be discarded. - Page 25 NATURAL GAS CONVERSION INSTRUCTIONS: Using 11 mm wrench, remove low-rate bypass tube from control valve. See Image 6.28. With a flat-blade screwdriver, remove valve orifice and replace with natural gas orifice specified on Pg. 6 of this manual. If no valve orifice is required, low-rate bypass tube can be reinstalled using 11 mm wrench.
- Page 26 Secure control valve to control panel with two (2) supplied Phillips head screws. Install control knob onto valve stem. See Image 6.32. Connect igniter and ground wire to sparker box. See Image 6.33. Both wires can connect to either connection point. The unit will operate in either configuration.
- Page 27 Carefully place burner assembly into enclosure. Evenly spread glass media over SPREAD MEDIA EVENLY MEDIA CAN BE PLACED ON SPREAD MEDIA EVENLY MEDIA CAN BE PLACED ON ACROSS BURNER SURFACE IGNITION WIND GUARD COVER ACROSS BURNER SURFACE IGNITION WIND GUARD COVER burner surface.
- Page 28 Other media options apart from the supplied clear glass gems can be used in Crystal Fire® Plus burners, but they should be supplied by the Outdoor GreatRoom Company . This ensures that the proper amount of media is used and that the media is approved for use in gas appliances.
-
Page 29: Lighting And Operation
LIGHTING AND OPERATION WARNING FIRE OR EXPLOSION HAZARD LOW/ IGNITION If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. HIGH PUSH AND HOLD TO IGNITE Verify control valve is in OFF position. See Image 7.1. If operating on a self-contained propane cylinder, ensure cylinder valve is CLOSED. -
Page 30: Troubleshooting
TROUBLESHOOTING SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTIONS Replace propane tank with full tank or Propane tank is empty. have propane tank filled and reattempt ignition. Close propane tank valve and Propane tank OPD has been activated. disconnect propane regulator hose This occurs when the Propane tank from tank. - Page 31 For additional troubleshooting information not detailed in this manual, please contact the dealer or location from which the product was purchased. If additional assistance is required: Visit https://www.outdoorrooms.com/product-support/faqs or contact The Outdoor GreatRoom Company at 1-866-303-4028 42508 REV B : CFP : 08-13-2019 www.outdoorrooms.com...
-
Page 32: Service And Maintenance
SERVICE AND MAINTENANCE A. REGULAR MAINTENANCE TASKS WARNING Installation and repair should be performed only by a qualified service technician. If using a self-contained propane gas supply system with the supplied propane regulator hose assembly, the hose should be inspected for damage BEFORE EACH USE OF THE APPLIANCE. -
Page 33: Cleaning The Appliance
B. CLEANING THE APPLIANCE Remove glass media and clean in basin of BURNER TRIM water mixed with dish soap. Allow to dry on a BURNER SURFACE towel. Use compressed air to remove any debris from the burner surface. See Image 9.4. Stainless steel burner trim can be cleaned and polished with commercially-available stainless steel cleaners and a polish such as Brasso... -
Page 34: Reference Materials
REFERENCE MATERIALS A. SERVICE PARTS LIST Part Description Part Number Variable Control Safety Valve For CFP1224 and CFP20 VCSV-S Variable Control Safety Valve For CFP1242, CFP2424, CFP30 VCSV-L ½” Female Flare X 3/8” Male Flare Adapter 050-F-FL-0375-M-FL 20 lb. Self-Contained Propane Cylinder Regulator Hose 10’ Length CF-HOSE-REG 22”... -
Page 35: Optional Parts
B. OPTIONAL PARTS Part Description Part Number 16” Long Whistle-Free Stainless Steel Flex-Line ½” Flare Fittings T200-9898-16 22” Long Whistle-Free Stainless Steel Flex-Line ½” Flare Fittings T200-9898-22 34” Long Whistle-Free Stainless Steel Flex-Line ½” Flare Fittings T200-9898-34 46” Long Whistle-Free Stainless Steel Flex-Line ½” Flare Fittings T200-9898-46 Ventilation Plate for Custom Enclosures 21005... -
Page 36: Dimensional Information
C. DIMENSIONAL INFORMATION All Dimensions are in Inches 21.06 19.38 15.87 14.97 CFP20 BI16 32.00 27.95 30.04 25.32 CFP30 BI28 17.10 17.10 23.69 23.69 19.64 25.60 19.64 25.60 CFP2424 BI1919 www.outdoorrooms.com 42508 REV C : CFP : 01-14-2020... - Page 37 All Dimensions are in Inches 25.63 19.63 17.24 23.68 11.56 5.04 7.42 13.50 BI719 CFP1224 42.52 36.52 40.58 34.00 11.56 CFP1242 BI737 5.04 13.50 7.42 57.00 64.30 62.36 55.87 CFP1264 BI757 11.56 5.17 13.50 7.42 42508 REV B : CFP : 08-13-2019 www.outdoorrooms.com...
- Page 38 All Dimensions are in Inches 72.00 70.06 66.00 63.75 5.17 7.42 BI766 11.56 CFP1272 13.50 84.00 82.06 78.00 75.75 BI778 5.17 CFP1284 7.42 11.56 13.50 96.00 94.06 90.00 87.75 5.17 7.42 11.56 BI790 CFP1296 13.50 www.outdoorrooms.com 42508 REV C : CFP : 01-14-2020...
- Page 39 All Dimensions are in Inches 108.00 102.00 106.06 99.75 5.17 CFP12108 BI7102 7.42 11.56 13.50 120.00 114.00 118.06 111.75 5.17 CFP12120 BI7114 7.42 11.56 13.50 42508 REV B : CFP : 08-13-2019 www.outdoorrooms.com...
-
Page 40: Appliance Information (Dsi Burners)
APPLIANCE INFORMATION (DSI BURNERS) A. APPLIANCE B. SPECIFICATIONS CERTIFICATION MODEL ORIFICE SIZE STANDARD INPUT RATE ® MODEL: ALL CRYSTAL FIRE NATURAL PLUS BURNERS & BURNER PROPANE PROPANE NATURAL GAS INSERTS WITH DIRECT SPARK IGNITION CFP20 55K BTU/hr. 55K BTU/hr. BI16 (16.12 kW) (16.12 kW) TESTING AGENCY: Underwriters... - Page 41 MODEL ORIFICE SIZE MAXIMUM INPUT RATE PROPANE NATURAL GAS PROPANE NATURAL GAS CFP20* 70K BTU/hr. (20.5 kW) 77.5K BTU/hr. (22.7 kW) BI16* CFP1224* 75K BTU/hr. (22.0 kW) 75K BTU/hr. (22.0 kW) BI719* CFP1242* .125” 100K BTU/hr. (29.3 kW) 100K BTU/hr. (29.3 kW) BI737* CFP1264 125”...
-
Page 42: Getting Started (Dsi Burners)
GETTING STARTED (DSI BURNERS) A. INCLUDED ITEMS Crystal Fire® Plus Burner Direct Spark Ignition (DSI) System (Connected to burner) Crystal Fire® Plus Instruction Manual UL Rating Label (Attached to burner) Power Adaptor Standard DSI Control Panel Emergency Stop Button and Control Panel (CFP-ESO-CP) Glass Media (See table below for number of media bags) -
Page 43: Tools And Supplies Required
B. TOOLS AND SUPPLIES REQUIRED Work Gloves Safety Glasses Utility Knife (for opening packaging) (2X) Adjustable Wrenches Corrosion-Free Leak Test Solution Small Flat-Blade Screwdriver Digital or Slack-Tube Manometer with ¼” ID Tube Attachment GFCI Outlet installed in accordance with local code. -
Page 44: Appliance Clearance Requirments (Dsi Burners)
APPLIANCE CLEARANCE REQUIREMENTS (DSI BURNERS) A. SURROUNDING CLEARANCES WARNING WARNING FIRE RISK FOR OUTDOOR USE ONLY Follow all minimum clearance requirements. Failure to provide adequate clearance to What qualifies an area as an outdoor space? combustible materials can result in property To qualify as an outdoor space, the area in damage or loss of life. -
Page 45: Enclosure Clearances For Cfp Models With Dsi
B. ENCLOSURE CLEARANCES FOR CFP MODELS WITH DSI WARNING Follow all minimum clearance requirements. Failure to provide adequate clearance to combustible materials can result in property damage or loss of life. Required Clearances to Combustibles LINEAR MODELS CFP1224 CFP1242 CFP1264 CFP12120 4 in. -
Page 46: Enclosure Clearances For Bi Models With Dsi
B. ENCLOSURE CLEARANCES FOR CFP MODELS WITH DSI WARNING Follow all minimum clearance requirements. Failure to provide adequate clearance to combustible materials can result in property damage or loss of life. Required Clearances to Combustibles LINEAR MODELS BI719 BI737 BI757 BI7114 7 in. -
Page 47: Enclosure Design Requirements (Dsi Burners)
ENCLOSURE DESIGN (DSI BURNERS) A. SELF-CONTAINED PROPANE CYLINDER INSTALLATIONS The Outdoor GreatRoom Company has vent blocks available for DIY landscape block projects as well as vent plates for other enclosures. See reference materials for more information. OPENINGS ARE SHOWN AS 5" X 2"... -
Page 48: Hard-Piped Propane Installations
B. HARD-PIPED PROPANE INSTALLATIONS The Outdoor GreatRoom Company has vent blocks available for DIY landscape block projects as well as vent plates for other enclosures. See reference materials for more information. OPENINGS ARE SHOWN AS 5" X 2" RECTANGLES A readily accessible GFCI outlet... -
Page 49: Hard-Piped Natural Gas Installations
B. HARD-PIPED NATURAL GAS CYLINDER INSTALLATIONS The Outdoor GreatRoom Company has vent blocks available for DIY landscape block projects as well as vent plates for other enclosures. See reference materials for more information. OPENINGS ARE SHOWN AS 5" X 2"... -
Page 50: Gas Setup And Information (Dsi Burners)
GAS SETUP AND INFORMATION (DSI BURNERS) • Pressure requirements for the appliance are WARNING: shown in the table below. Pressure readings must be attained WHILE THIS APPLIANCE AND ALL FIRE AND EXPLOSION RISK: OTHER GAS APPLIANCES ARE IN OPERATION. VERIFY INLET PRESSURES •... -
Page 51: Leak Check And Line Purge
E. ADDITIONAL GAS SUPPLY D. LEAK CHECK AND LINE PURGE INFORMATION Once the gas piping system is in place, all fittings and connections need to be checked for For propane installations using a non-disposable, leaks. self-contained propane supply system (20 lb. propane tank and the manufacturer supplied Use a commercially-available, non-corrosive regulator hose):... -
Page 52: Burner Installation (Dsi Burners)
Other media options apart from the supplied clear glass gems can be used in Crystal Fire® Plus burners, but they should be supplied by the Outdoor GreatRoom Company . This ensures that the proper amount of media is used and that the media is approved for use in gas appliances. - Page 53 With burner sitting on top of enclosure, connect control switch to DSI system. The connector is keyed and will only connect one way. See Image 16.3. It may be necessary to prop up burner in one or more locations. With burner in same position as in Step 3, connect power adaptor to DSI system.
- Page 54 Turn control switch to ON position to verify pres- ence of power and spark location. Look inside ig- SPARK LOCATION nition wind guard for visible spark. See Image 16.7. After spark is confirmed, turn control switch back to OFF position. Ensure propane cylinder valve is closed.
-
Page 55: Hard-Piped Propane Installations
B. HARD-PIPED PROPANE INSTALLATIONS WARNING Installation and repair should be performed only by a qualified service technician. Secure supplied control panel to enclosure with suitable fasteners. See Image 16.11. If burner is being installed in an Outdoor GreatRoom (Img. 16.11) Company™... - Page 56 With burner in same position as in Step 3, connect power adaptor to DSI system. The connections will be labelled 3.3 VDC + and 3.3 VDC – on both the DSI system and power adaptor. If they are not connected properly, the unit will not operate.
- Page 57 For units set up for propane with an attached regulator hose, it is necessary to remove the hose and flare adaptor. Connect main gas supply to ½” male flare fitting on INLET side of DSI system. See Image 16.18. The Outdoor GreatRoom Company™...
- Page 58 Overfilling of the burner with media can cause adverse operational issues. Use of burner media other than that supplied by The Outdoor GreatRoom Company™ is not recommended and could lead to operational issues. www.outdoorrooms.com 42508 REV C : CFP : 01-14-2020...
-
Page 59: Lighting And Operation (Dsi Burners)
LIGHTING AND OPERATION (DSI BURNERS) WARNING FIRE OR EXPLOSION HAZARD If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. REMOTE Verify control switch is in OFF position. See Image 17.1. If operating on a self-contained propane cylinder, ensure cylinder valve is CLOSED. -
Page 60: Troubleshooting (Dsi Burners)
TROUBLESHOOTING (DSI BURNERS) SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTIONS Replace propane tank with full tank or Propane tank is empty. have propane tank filled and reattempt ignition. Gas supply individual shutoff valve is Open individual shutoff valve on gas closed. supply and reattempt ignition. Ensure media placement instructions Excessive media buildup around are followed so that media is not... - Page 61 For additional troubleshooting information not detailed in this manual, please contact the dealer or location from which the product was purchased. If additional assistance is required: Visit https://www.outdoorrooms.com/product-support/faqs or contact The Outdoor GreatRoom Company at 1-866-303-4028 42508 REV B : CFP : 08-13-2019 www.outdoorrooms.com...
-
Page 62: Service And Maintenance (Dsi Burners)
TROUBLESHOOTING (DSI BURNERS) A. REGULAR MAINTENANCE TASKS WARNING Installation and repair should be performed only by a qualified service technician. If using a self-contained propane gas supply system with the supplied propane regulator hose assembly, the hose should be inspected for damage BEFORE EACH USE BURNER TRIM OF THE APPLIANCE. -
Page 63: Cleaning The Appliance
B. CLEANING THE APPLIANCE BURNER TRIM BURNER SURFACE Remove glass media and clean in basin of water mixed with dish soap. Allow to dry on a towel. Use compressed air to remove any debris from the burner surface. See Image 9.4. Stainless steel burner trim can be cleaned and polished with commercially-available stainless steel cleaners and a polish such as Brasso... -
Page 64: Reference Materials (Dsi Burners)
REFERENCE MATERIALS (DSI BURNERS) A. BATTERY PACK INSTALLATION AND OPERATION CLEAN HERE If ordered with a DSI burner, the optional CLEAN HERE battery pack (CF-DSI-BP) will be attached to the DSI mounting bracket and connected to the wiring harness. Proceed to Step 4. (Img. -
Page 65: Remote Pairing And Operation
Other sources of radio-frequency interference (air conditioners, bug zappers, cellular network towers, etc.) can all affect the operating range of the CF-DSI-R. INDICATOR LIGHT The Outdoor GreatRoom Company , LLC makes no LEARN BUTTON guarantees on operating range of the remote due to the variety of applications in which a DSI appliance may be (Img. - Page 66 WARNING REMOTE PAIRING AND OPERATION Pressure testing should be performed only by Close main gas supply shutoff valve. a qualified gas professional. Open DSI control box by rotating the locking tabs as shown. See Image 20.8. Using a small flat-blade screwdriver, carefully unscrew INLET pressure tap on gas control valve.
-
Page 67: Standard Wiring Diagram
D. STANDARD WIRING DIAGRAM This wiring diagram depicts the standard configuration of the Direct Spark Ignition system. For wiring diagrams of additional configurations, refer to 42511 Crystal Fire® Plus Supplemental Commercial Manual. SENSOR/IGNITER STANDARD CONTROL SWITCH 3.3 VDC+ 110-120VAC SUPPLY FROM GFCI 3.3 VDC- RECEPTACLE CONTROL... -
Page 68: Service Parts
E. SERVICE PARTS LIST Part Description Part Number Direct Spark Ignition System Control Module OGR-6KR-NT Direct Spark Ignition System CF-DSI-ELECTRODE Direct Spark Ignition Standard Control Switch CF-DSI-WH Power Adaptor for Direct Spark Ignition System OGR-3V-ADP Wind Guard for Direct Spark Ignition System 70010 ½”... -
Page 69: Optional Parts
F. OPTIONAL PARTS Part Description Part Number Remote Transmitter for DSI System CF-DSI-R Direct Spark Ignition System CF-DSI-BP Ventilation Plate for Custom Enclosures 21005 Ventilation Block for Landscape Block enclosures VENT BLOCK BLK DSI Control Panel for Landscape Block Enclosures DSI-DIY-CP 16”... - Page 70 G. DIMENSIONAL INFORMATION All Dimensions are in Inches 15.87 21.06 14.87 19.38 15.87 14.87 CFP20 BI16 28.00 28.00 32.00 25.32 25.32 30.00 15.30 GAS OUTLET: 4.74 4.74 GAS INLET: 1.97 1.97 5.36 5.50 MBED TO BURNER 1/2 IN. MALE FLARE MANUFACTURER ON 3/8 IN.
- Page 71 All Dimensions are in Inches 19.63 17.24 7.42 5.04 23.68 7.42 25.63 11.56 13.50 19.63 BI719 CFP1224 9.73 42.52 36.52 40.58 34.00 4.40 4.07 6.07 1.24 1.09 1.25 THE OUTDOOR REV ECR DATE DESCRIPTION DRAWN BY DATE UNLESS OTHERWISE SPECIFIED GREATROOM TOLERANCES: 7/29/19...
- Page 72 All Dimensions are in Inches 72.00 66.00 70.06 63.75 7.42 66.00 5.17 11.56 BI766 7.42 CFP1272 13.50 3.05 9.75 12.48 1.24 84.00 82.06 78.00 75.75 GAS OUTLET: 4.07 PLUMBED TO BURNER S INLET: 1.24 BY MANUFACTURER E FLARE 4.40 M PIPE 1.24 1.24 6.07...
- Page 73 All Dimensions are in Inches 108.00 102.00 106.06 99.75 7.42 CFP12108 5.17 BI7102 7.42 11.56 102.00 13.50 3.05 9.75 14.26 12.48 1.24 GAS OUTLET: PLUMBED TO BURNER 4.07 GAS INLET: 1.24 BY MANUFACTURER 1/2" MALE FLARE ON 3/8" NPTM PIPE 1.24 4.40 4.33...
-
Page 74: Warranty Information
The maximum amount recoverable under this warranty is limited to the purchase price of the Product and, if The Outdoor GreatRoom Company unable to provide replacement or repair in an expedient and cost-effective manner, The Outdoor... - Page 75 PRODUCT CATEGORY WARRANTY INFORMATION Limited lifetime warranty on all stainless steel burners installed in a residential setting, and 5 years on all stainless steel burners installed in a commercial setting. GAS FIRE PIT TABLES/CRYSTAL One year warranty on ignition & electronics FIRE®...
