Danfoss Optyma Plus Series Manual page 4

Manual
Model* Optyma
Code
New Generation
(controller
parameter
settings are adjustable*
o61 )*
1 OP-MPHM007NFP00G
2 OP-MPHM010SCP00G
3 OP-MPHM012SCP00G
4 OP-MPHM015SCP00G
5 OP-MPHM018SCP00G
6 OP-MPGM034GSP00G
7 OP-MPHM026GSP00G
8 OP-MPHM034GSP00G
20 OP-LPHM018SCP00G
21 OP-LPHM026GSP00G
22 OP-LPQM017MPP00G
22 OP-LPQM026AJP00G
22 OP-LPQM074FHP00G
22 OP-LPQM074FHP00E
22 OP-LPQM048NTP00G
23 OP-LPQM048NTP00E
24 OP-LPQM068NTP00G
25 OP-LPQM068NTP00E
26 OP-LPQM096NTP00E
27 OP-LPQM136NTP00E
28 OP-MPYM008MYP00G
28 OP-MPYM009MYP00G
28 OP-MPYM012MPP00G
28 OP-MPYM014MPP00G
28 OP-MPBM018AJP00G
28 OP-MPBM024AJP00G
28 OP-MPBM026AJP00G
28 OP-MPBM026AJP00E
28 OP-MPBM034AJP00G
28 OP-MPBM034AJP00E
28 OP-MPXM034MLP00G
29 OP-MPXM034MLP00E
30 OP-MPXM046MLP00G
31 OP-MPXM046MLP00E
32 OP-MPXM068MLP00G
33 OP-MPXM068MLP00E
34 OP-MPXM080MLP00G
35 OP-MPXM080MLP00E
36 OP-MPXM108MLP00E
37 OP-MPXM125MLP00E
38 OP-MPXM162MLP00E
39 OP-LPQM215LLP00E
40 OP-LPQM271LLP00E
41 OP-MPXM057MLP00G
42 OP-MPXM057MLP00E
52 OP-MPGM033AJP00G
55 OP-MPLM028VVZP01E
55 OP-MPPM028VVZP01E
56 OP-MPLM035VVZP01E
56 OP-MPPM035VVZP01E
57 OP-MPLM044VVZP01E
57 OP-MPPM044VVZP01E
Code (controller parameter o61): Kode (regulatorparameter o61) / Code (Reglerparameter o61) / Code (contrôleur paramètre o61) / Code (controller parameter o61)
Model : Model / Modell / Modèle / Modell
Code-no. : Bestillingsnr. / Art-Nr. / Code n° / Artikelnummer
Compressor : Kompressor / Verdichter / Compresseur / Kompressor
Refrigerant : Kølemiddel (regulatorparameter o30) / Kältemittel (Reglerparameter o30) / Réfrigérant (contrôleur paramètre o30) / Köldmedium
*Settings are adjustable : indstillinger er justerbare / Werte einstellbar / parameters sont réglables / Inställningarna kan justeras
4
BC08728642552802-001001
Controller Installation
Plus
™
Code-no. Compressor*
114X4101 NF7MLX
114X4102 SC10MLX
114X4104 SC12MLX
114X4105 SC15MLX
114X4109 SC18MLX
114X4210 GS34MFX
114X4214 GS26MLX
114X4229 GS34MLX
114X3109 SC18CLX.2
114X3217 GS26CLX
114X3118 MPT16LA
114X3216 CAJ2446Z
114X3252 FH2511Z
114X3253 TFH2511Z
114X3225 NTZ48-5VM
114X3233 NTZ48-4VM
114X3241 NTZ68-5VM
114X3249 NTZ68-4VM
114X3357 NTZ96-4VM
114X3365 NTZ136-4VM
114X4119 MLY80RAb
114X4120 MLY90RAb
114X4121 MPT12RA
114X4122 MPT14RA
114X4230 CAJ9510Z
114X4200 CAJ9513Z
114X4212 CAJ4517Z
114X4213 TAJ4517Z
114X4226 CAJ4519Z
114X4227 TAJ4519Z
114X4261 MLZ015T5LP9
114X4264 MLZ015T4LP9
114X4281 MLZ021T5LP9
114X4284 MLZ021T4LP9
114X4308 MLZ030T5LC9
114X4311 MLZ030T4LC9
114X4321 MLZ038T5LC9
114X4324 MLZ038T4LC9
114X4344 MLZ048T4LC9
114X4414 MLZ058T4LC9
114X4434 MLZ076T4LC9
114X3476 LLZ024T4LC9
114X3482 LLZ034T4LC9
114X4290 MLZ026T5LP9
114X4293 MLZ026T4LP9
114X4220 CAJ4511Y
114X4300 VLZ028TGA
114X4302 VLZ028TGA
114X4316 VLZ035TGA
114X4316 VLZ035TGA
114X4334 VLZ044TGA
114X4334 VLZ044TGA
Refrigerant (controller parameter o30)*
Factory R404A R507 R134a
Presetting (19) (17) (3)
R404A x x
R404A x x
R404A x x
R404A x x
R404A x x
R134a x
R404A x x
R404A x x
R404A x x
R404A x x
R452A x x
R452A x x
R452A x x
R452A x x
R452A x x
R452A x x
R452A x x
R452A x x
R452A x x
R452A x x
R449A x x
R449A x x
R449A x x
R449A x x
R449A x x
R449A x x
R449A x x
R449A x x
R449A x x
R449A x x
R449A x x x
R449A x x x
R449A x x x
R449A x x x
R449A x x x
R449A x x x
R449A x x x
R449A x x x
R449A x x x
R449A x x x
R449A x x x
R452A x x
R452A x x
R449A x x x
R449A x x x
R134a x
R404A x x
R449A x x
R404A x x
R449A x x
R404A x x
R449A x x
R513A R407A R407F R448A
(13) (21) (37) (40)
x x x x
x x x x
x x x x
x x x x
x x x x
x x x x
x x x x
x x x x
x x x x
x x x x
x x x x
x x x x
x x x x
x
x x
x x x
x x
x x x
x x
x x x
R449A R452A
(41) (42)
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x
x
x x
x x
x
x
x
