- Page 2 IQ plus 2100 ® Digital Bench Scale Version 1 Installation Manual PN 53415 Rev A...
-
Page 4: Table Of Contents
Course descriptions and dates can be viewed at www.ricelake.com/training or obtained by calling 715-234-9171 and asking for the training department. © Rice Lake Weighing Systems. All rights reserved. Printed in the United States of America. Specifications subject to change without notice. - Page 5 6.4 Specifications ..............36 Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost.
-
Page 6: Introduction
Overview The IQ plus 2100 digital bench scale consists of an IQ plus 210 digital weight indicator and an RL2100 bench scale. The indicator can be mounted to the bench scale using the 12” column or the attachment bracket, or can be separately mounted on the tilt stand. -
Page 7: Front Panel
If more than one alternate unit is configured, the display cycles through the alternate units before returning to primary units; if no alternate units are configured, the display does not change when the button is pressed. IQ plus 2100 Installation Manual... -
Page 8: Installation
Installation The IQ plus 2100 digital bench scale is designed for easy setup and installation. All models are pre-configured and weight calibrated before shipment, with the load cell connected to the indicator. For simple, standalone scale applications, hardware installation consists of attaching the indicator, mounting assembly, and bench scale, then leveling the scale. -
Page 9: Indicator
Route stripped cables through cord grips and clamps. Ensure shields contact grounding clamps as shown in Figure •. Tighten grounding clamp nuts. • Finish installation using cable mounts and ties to secure cables inside of indicator enclosure. IQ plus 2100 Installation Manual... -
Page 10: Load Cells
Microprocessor SERIAL COMM RESET DIGITAL ANALOG TEST TEST Tr a n s f o r m e r A / D C o n v e r t e r To setup switch U N I T S Z E R O B u t t o n B u t t o n LOAD CELL CONNECTOR... -
Page 11: Serial Communications
2. Remove connections to J5 (load cell cable), J7 (serial communications), J2 and J3 (digital inputs), J4 and J6 (piezo button inputs), and J1 (setup switch). Remove blue and brown power input wires at J8. See Figure 2-2 on page 5 for connector locations. IQ plus 2100 Installation Manual... -
Page 12: Bench Scale
3. Remove the five nuts from the CPU board, then lift the board out of the enclosure. To replace the CPU board, reverse the above procedure. Be sure to reinstall cable ties to secure all cables inside the indicator enclosure. Bench Scale This section provides instructions for replacing load cell, adjusting lift-up and overload protection screws and installing the optional clamshell enclosure. -
Page 13: Bench Scale Adjustments
Screw Height (D) 5 lb (2.5 Kg) 0.56 in (142 mm) 10 lb (5 Kg) 0.50 in (127 mm) 25 lb (10 Kg) 50 lb (25 Kg) 100 lb (50 Kg) Table 2-4. Corner Protection Screw Height IQ plus 2100 Installation Manual... - Page 14 6.6.3 Clamshell Installation Protective stainless steel clamshells are available as an option for all RL2100 bench scales. Clamshells are pre-drilled for load cell screws, overload screw, and cables. Existing load cell shims are reinstalled inside the clamshells. To install the clamshell, do the following: 1.
-
Page 15: Iq Plus 210 Indicator Repair Parts
From Line Filter From Power Cord See Detail B To CPU J1 To Display Board Detail B Input Power J8 Detail A Ground Post Assembly Inside Bottom Plate Figure 2-7. IQ Plus 210 Indicator Parts Illustration IQ plus 2100 Installation Manual... - Page 16 Item Part No. Description 14626 Kep nuts, 8-32NC hex 53651 Display and CPU board assembly, 115 VAC 53650 Display and CPU board assembly, 230 VAC 15365 Board mounting spacers 52483 Enclosure backplate 15626 Cable grips, PG9 30375 Nylon seal rings for cable grips 15627 Locknuts, PCN9 19538...
-
Page 17: Rl2100 Replacement Parts
RL2100 Replacement Parts Figure 2-8. RL2100 Repair Parts Illustration IQ plus 2100 Installation Manual... - Page 18 Item Part Number Description 51332 Platter, 10x10 51333 Platter, 12x12 50880 Spider plate, 10x10 51335 Spider plate, 12x12 50881 Base, 10x10, 5-Lb model 63233 Base, 10x10, 10- & 25-Lb models 63430 Base, 12x12 — Single Point Load cell 35082 Upper load cell shim, 10x10 models 52383 Upper load cell shim, 12x12 models 15410...
- Page 19 Figure 2-9. IQ Plus 210 Tilt Stand Assembly Item No. Part No. Description 29635 Tilt stand 42149 Tilt stand feet 15144 Nylon washers, 1/4x1x1/16 30342 Wing knobs Table 2-7. IQ Plus 210 Tilt Stand Assembly Parts List IQ plus 2100 Installation Manual...
- Page 20 Figure 2-10. Attachment Bracket Assembly Parts Illustration Item Part No. Description 50879 Attachment bracket 15408 Rubber grommet, 3/16 ID 14956 Cap screws, 1/4-20NC x 1/2 15148 Lock washers, 1/4 14645 Jam nuts, 1/4-20NC hex SST 35128 Bench scale feet, 1/4-20NC 30342 Wing knobs 15144...
- Page 21 12-inch column 15148 Lock washers, 1/4 14956 Cap screws, 1/4-20NC x 1/2 14645 Jam nuts, 1/4-20NC hex SST 35128 Bench scale feet, 1/4-20NC 30342 Wing knobs 15144 Nylon washers, 1/4x1x1/16 Table 2-9. Column Assembly Parts List IQ plus 2100 Installation Manual...
-
Page 22: Configuration
Configuration To configure the IQ plus 210 indicator, the indicator must be placed in setup mode. The setup switch is accessed by removing the large fillister head screw on the enclosure backplate. Insert a screwdriver into the access hole and press the switch to enter setup mode. -
Page 23: Edp Command Configuration
RIGHT button scrolls right (horizontally) on the same menu level; the ) button moves down (vertically) to ZERO ENTER different menu levels and serves as an Enter key for selecting parameter values within the menus. IQ plus 2100 Installation Manual... -
Page 24: Menu Navigation
Most of the configuration menus have three or four levels. Figure 3-3 shows the general structure of the IQ plus 210 configuration menus. Note the following: • On the first (main) menu level, press to scroll through the menus. Pressing from the RIGHT RIGHT... - Page 25 Press ENTER to save the value entered and return to the menu level above, or press to edit the value again, RIGHT starting with the leftmost digit. Figure 3-5. Editing Procedure for Numeric Values IQ plus 2100 Installation Manual...
-
Page 26: Menu Structures And Parameter Descriptions
Menu Structures and Parameter Descriptions The following sections provide graphic representations of the IQ plus 210 menu structures. In the actual menu structure, the values under each parameter are arranged horizontally. To save page space, menu choices are shown in vertical columns. The factory default setting appears at the top of each column. Most menu diagrams are accompanied by a table that describes all parameters and parameter values associated with that menu. -
Page 27: Format Menu
FORMAT CALIBR SERIAL XXXXXXX DIG IN DEFLT VERS PRIMAR ALTUNT UNITS DECPNT DSPDIV LB/OZ 888.888 8888.88 88888.8 888888 LB/OZ 888880 8.88888 88.8888 If UNITS=LB/OZ, DECPNT selections are: 88 88.8 888 88 Figure 3-7. Format Menu IQ plus 2100 Installation Manual... - Page 28 FORMAT Menu Parameter Choices Description Level 2 submenus PRIMAR UNITS Specifies the decimal position, display divisions, and units used for the primary units. See DECPNT Level 3 submenu parameter descriptions. DSPDIV ALTUNT Specifies which alternate units can be displayed by pressing the UNITS. See Level 3 submenu parameter descriptions.
-
Page 29: Calibration Menu
Baud rate. Selects the transmission speed for the serial port. 1200 2400 4800 BITS 8NONE Selects number of data bits and parity of data transmitted from the serial port. 7EVEN 7ODD Table 3-5. Serial Menu Parameters IQ plus 2100 Installation Manual... -
Page 30: Digital Input Menu
SERIAL Menu Parameter Choices Description TERMIN CR/LF Termination character. Selects termination character for data sent from the serial port. ECHO This command enables or disables echoing of the serial commands sent to the indicator. PRNFRQ DEMAND Print frequency. Specifies when the indicator sends data to the serial port: AUTO1 DEMAND:When a PRINT digital input is activated or the KPRINT EDP command received. -
Page 31: Default Menu
The VERS menu is used to check the software version installed in the indicator. There are no parameters associated with the VERS menu: when selected, the indicator displays the installed software version number. CONFIG XXXXXXX FORMAT CALIBR SERIAL XXXXXXX DIG IN DEFLT VERS Software version Figure 3-12. Version Menu IQ plus 2100 Installation Manual... -
Page 32: Calibration
Calibration ™ The IQ plus 210 can be calibrated using the front panel, EDP commands, or the Revolution configuration utility. Each method consists of the following steps: • Zero calibration • Entering the test weight value • Span calibration • Optional rezero calibration for test weights using hooks or chains. -
Page 33: Edp Command Calibration
2. On the Weight Calibration display, select the indicator model ( ) and communications port then click IQ+210 3. Revolution uploads calibration data from the indicator then presents the information in a display like that shown in Figure 4-3. IQ plus 2100 Installation Manual... - Page 34 4. Enter the to be used for span calibration then click Value of Test Weight 5. The Zero Calibration dialog box prompts you to remove all weight from the scale. Clear the scale and click to begin zero calibration. If your test weights require hooks or chains, place the hooks or chains on the NOTE: scale for zero calibration.
-
Page 35: Edp Commands
All load cell calibration settings are lost when the RESETCONFIGURATION command is run. 5.1.4 Parameter Setting Commands Parameter setting commands allow you to display or change the current value for a particular configuration parameter (Tables 5-3 through 5-8). IQ plus 2100 Installation Manual... - Page 36 Current configuration parameter settings can be displayed in either setup mode or normal mode using the following syntax: command<ENTER> Most parameter values only can be changed in setup mode. Use the following command syntax when changing parameter values: command=value<ENTER> where is a number or a parameter value.
-
Page 37: Normal Mode Commands
Communication between the PC and indicator will be lost once the indicator receives settings for baud rate (BAUD parameter) or data bits and parity (BITS parameter) that do not match those configured for the PC. IQ plus 2100 Installation Manual... -
Page 38: Appendix
Section 6.1.2. Error Message Description Solution E A/D A/D physical error Call Rice Lake Weighing Systems (RLWS) Service. EEEROM EEPROM physical error EVIREE Virgin EEPROM Use the DEFLT menu to restore defaults, then recalibrate load cells. EPCKSM Parameter checksum error... -
Page 39: Status Messages
136 represents the sum of the values for the center of zero annunciator (128) and the lb annunciator (8). Decimal Value Annunciator Reserved Negative value Table 6-3. Status Codes Returned on the ZZ Command IQ plus 2100 Installation Manual... -
Page 40: Continuous Output (Stream) Format
Continuous Output (Stream) Format Figure 6-1 shows the continuous output format sent to the IQ plus 210 EDP or printer port when the STREAM parameter (SERIAL menu) is set to either EDP or PRN. <STX> <POL> <wwwwwww> <UNIT> <G> <S> <TERM>... -
Page 41: Specifications
(305 mm x 305 mm) 50 lb (25 Kg) LED annunciators Negative value, center of zero, motion, 100 lb (50 Kg) kg, g, lb, oz Keypad 2 piezo switches Approvals NTEP CoC Number 95-072A2 Accuracy Class Measurement Canada Approved Approval AM-5082 Rev 1 IQ plus 2100 Installation Manual... - Page 43 Specifications subject to change without notice. Rice Lake Weighing Systems is an ISO 9001 registered company. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319 www.ricelake.com www.ricelake.mx www.ricelake.eu www.ricelake.co.in...
