Speakers - HP OMEN Maintenance And Service Manual

Speakers

Table 6-2 Speaker description and part number
Description
Speaker assembly (includes cable)
Before removing the speaker, follow these steps:
1. Prepare the computer for disassembly
2. Remove the base enclosure (see
3. Remove the battery (see
4. Remove the hard drive (see
5. Remove the solid-state drive (see
Remove the speakers:
1. Disconnect the speaker cable (1) from the system board.
2. Remove the two Phillips 6 mm screws (2) that secure the speakers to the computer.
3. Release the speaker cable (3) from the clips that secure it to the computer.
4. Lift the speakers (4) to remove them from the computer.
Reverse this procedure to install the speakers.
46 Chapter 6 Removal and replacement procedures for authorized service provider parts
(Preparation for disassembly on page
Base enclosure on page
Battery on page 45).
Hard drive (HDD) on page
Solid-state drive (SSD) on page
34).
34).
37).
39).
Spare part number
L14368-001
