Overview

This instruction sheet details installation of the three components listed below. Follow the instructions for to
the component being replaced. Refer to the exploded view diagram for parts reference and overview.

Packing List

Combustor Brick (250-00141)
Combustor Brick
Combustor Brick Gasket
Interram Gasket

Exploded View Diagram

Apply penetrating oil (WD40) to the bolts
prior to removal to prevent stripping.
7
1
ID #
Description
1
Side Brick
3
Inter-Ram Gasket
5
Back Brick
7
Brick Retainers with Bolts
9
Push Plugs (pack of 4)
Page 1 of 4
Leyden / Arbor Firebox Parts Installation
Back Plate (250-00704)
Back Plate
(2) Push Plugs
(4) ¼-20 1-1/2" Bolts
(4) ¼-20 Brass Nuts
7
3
2
4
Qty
Part #
2
250-00139
1
250-00294
1
250-00140
1
250-00144
2
92-1360
Printed 6/24/08
(see part numbers below)
6
5
1
ID #
Description
2
Combustor Brick w 2 Gaskets
4
Combustor Brick Gasket
6
Firebox Back w 4 Nuts & Bolts
8
Combustor Pack with Gaskets
Combustor (250-00247)
Combustor (with gaskets
attached)
8
9
This nut is located on
the exterior of the stove
beneath the rear heat
shield.
Qty
Part #
1
250-00141
1
250-00145
1
250-00704
1
250-00247
© Travis Industries, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Leyden and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Travis Industries Leyden

  • Page 1 Leyden / Arbor Firebox Parts Installation (see part numbers below) Overview This instruction sheet details installation of the three components listed below. Follow the instructions for to the component being replaced. Refer to the exploded view diagram for parts reference and overview.
  • Page 2 Leyden / Arbor Firebox Parts Installation (see part numbers below) Combustor Brick Installation The bolts inside the firebox may become difficult to remove after the stove has been burned. Apply penetrating oil (WD40™) to the bolts 5 minutes prior to removal to prevent stripping or breaking the bolts.
  • Page 3 Leyden / Arbor Firebox Parts Installation (see part numbers below) Back Plate Installation 1. Follow the instructions for removing the combustor brick (see page 2). 2. Remove the bypass ratcheting mechanism from the stove (see Figure 4). Remove the heat shield from the back of the stove, exposing the four brass nuts holding the back plate in place (see Figure 5).
  • Page 4 Leyden / Arbor Firebox Parts Installation (see part numbers below) Combustor Installation 1. Follow the instructions for removing the combustor brick (see page 2). 2. Follow the instructions for removing the back plate (see page 3). 3. Apply penetrating oil (WD40™) to the two nuts holding the bypass assembly to the stove top and the two bolts holding it to the back of the stove.
