Maintenance checklist

Cleaning the microphone protector

Clean the microphone protector daily with a soft brush or cloth,
while it is positioned on your processor. Do not clean the underside
of the protector. Do not use chemicals.

Replacing the microphone protector

Replace the microphone protector when sound quality is degraded
or when it becomes dirty. If you are unsure if it needs to be replaced,
try using a new protector and if the sound quality improves or is
louder then dispose of the old protector. Replace the protector every
month (at the very least) to ensure optimal sound quality.
1. Pull out the coil by
holding the plug
f i rmly.
4. Attach the new
protector.
© Cochlear Limited 2011
Do not pull the cable. 3. Remove the dirty
protector using your
f i ngernail.
Freedom Quick Start Guide - 17
