7
Ensure that the Bus Power Supply is installed correctly and powered on. For
instructions, see the Bus Power Supply Installation Guide.
Operation and Configuration
On initial power up, all status LEDs on the keypad will illuminate green, indicating
that the device has power. Until the keypad has been configured into a Control4
system, it will not control any loads. To set up this keypad for use with a Control4
system, refer to the Composer Pro User Guide.
Button Tap Sequences
The button tap sequences are defined in the table below. Button tap sequences
that require a single (1) button should use the top-most button installed on the
keypad. Button tap sequences requiring two (2) buttons should use the top-most
and bottom-most (or bottom-left) buttons installed on the keypad.
Function
Identify
Reboot
Factory Reset
Troubleshooting
If the LEDs do not light up indicating that the keypad is receiving power::
•
Ensure the Bus Power Supply is powered on.
•
Ensure the Bus Ethernet Gateway is powered on and connected.
•
Check for proper wiring (see "Installation Instructions" above).
•
For help on the installation or operation of this product, email or call the
Control4 Technical Support Center. Provide your exact model number.
Contact support@control4.com or see the website www.control4.com
Care and Cleaning
•
Do NOT paint the keypad or its wall plate.
•
Do NOT use any chemical cleaners to clean the keypad.
•
Clean surface of the keypad with a soft damp cloth as needed.
Button Sequence
1
15
9-4-9
Regulatory/Safety Information
To review Regulatory information for your particular Control4 products, see the
information located on the Control4 website at:
http://www.control4.com/regulatory/.
Patent Information
Applicable patents are available at http://www.control4.com/legal/patents.
Warranty
For complete warranty information, including details on consumer legal rights as
well as warranty exclusions, review the Warranty card or visit www.control4.com/
warranty.
About this Document
Part Number: 200-00346, Rev. A 5/2/2013
