Summary of Contents for SHOWTEC 40312
- Page 1 MANUAL ENGLISH LED Aircone DMX Ordercode: 40312 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
DIP switch setting for DMX Mode ..........................11 DMX Address Quick Reference Chart .........................12 DMX Channels .................................13 6 channels .................................13 Maintenance ..................................14 Replacing the Fuse ..............................14 Troubleshooting ................................15 No Light ..................................15 No Response to DMX..............................15 Product Specifications ..............................17 Dimensions ..................................18 Ordercode: 40312... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec LED Aircone DMX with 1m powercable ● User manual LED Expected Lifespan LEDs gradually decline in brightness over time. - Page 4 • If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
UK Cable US Cable BROWN YELLOW/COPPER PHASE BLUE BLACK SILVER NEUTRAL YELLOW/GREEN GREEN GREEN PROTECTIVE GROUND Make sure that the device is always connected properly to the earth! Improper installation can cause serious damage to people and property! Ordercode: 40312... -
Page 6: Return Procedure
After this period complaints will not be handled anymore. Complaints will only then be considered if the client has so far complied with all parts of the agreement, regardless of the agreement of which the obligation is resulting. Ordercode: 40312... -
Page 7: Description Of The Device
LED Aircone DMX Description of the device Features The Showtec LED Aircone DMX is a laser effect with high output and great effects. • Never change lamps again! • Power Input: AC 240V, 50Hz • Power Consumption: 150 Watt •... -
Page 8: Installation
Auto Mix Color Manual Mode One LED Aircone (Sound-controlled) 12) When dipswitch #10 is turned on, the Aircone will automatically change its color to the beat of the music. 13) With the Audio Sensitivity control you can adjust its music-sensitivity. Ordercode: 40312... -
Page 9: One Led Aircone (Auto Mix Color Control)
02) Fasten the effect light onto firm trussing (Use a 30-kg rated or stronger C-clamp bolted onto the Showtec LED Aircone bracket) or set the LED Aircone down on any flat surface. Leave at least 0,5 meter on all sides for air circulation. - Page 10 Do not supply power before the whole system is set up and connected properly. Multiple LED Aircones DMX Set Up Fig. 03 Note: Link all cables before connecting electric power Ordercode: 40312...
-
Page 11: Fixture Linking
DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by Neutrik®. Ordercode FL71150 (1,5m.), FL713 (3m.), FL716 (6m.), FL7110 (10m.). The LED Aircone DMX can be operated with a controller in control mode or without the controller in stand-alone mode. Ordercode: 40312... -
Page 12: Dip Switch Setting For Dmx Mode
Addresses on the LED Aircone DMX are set by flipping the appropriate DMX DIP switches. You need to know that DMX address settings are the sum of the DIP switch values. A standard DMX address for a Showtec LED Aircone, which has 6 channels is as follows: Example 1... -
Page 13: Dmx Address Quick Reference Chart
LED Aircone DMX DMX Address Quick Reference Chart Ordercode: 40312... -
Page 14: Dmx Channels
Channel 5 – Speed (CH6 must be set between 32-223 0-255 From slow to fast Channel 5 – No Function when CH6 is set between 224-255 Channel 6 – Modi 0-31 Color Setting 32-63 Lightness decreasing (Fade Out) 64-95 Lightness increasing (Fade In) Ordercode: 40312... -
Page 15: Maintenance
Sound-controlled Maintenance The Showtec LED Aircones requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply and then wipe the cover with a damp cloth. Wipe the front glass panel clean with glass cleaner and a soft cloth. -
Page 16: Troubleshooting
Response: Suspect three potential problem areas as: the power supply, the laser, the fuse. 01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The LEDs. Return the LED Aircone to your Showtec dealer. 03) The fuse. Replace the fuse. See page 14 for replacing the fuse. - Page 17 No light or laser LEDs damaged ● Disconnect fixture and return to your cuts out dealer. intermittently The power supply settings do not ● Disconnect fixture. Check settings and match local AC voltage and correct if necessary. frequency. Ordercode: 40312...
-
Page 18: Product Specifications
Compact strong metal housing Sound-controlled via built-in microphone Max. ambient temperature t 40°C Minimum distance: Minimum distance from flammable surfaces: 0.5m Minimum distance to lighted object: Design and product specifications are subject to change without prior notice. Website: www.Showtec.info Email: service@highlite.nl Ordercode: 40312... -
Page 19: Dimensions
LED Aircone DMX Dimensions Ordercode: 40312... - Page 20 ©2015 Showtec...
