Modbus TCP – Modbus RTU
TM
Intesis
3.2.5 Sending the configuration to Intesis
When the configuration is finished, follow the next steps.
1.- Click on Save button to save the project to the project folder on your hard disk (more information in Intesis
MAPS User Manual).
2.- You will be prompted to generate the configuration file to be sent to the gateway.
a.- If Yes is selected, the file containing the configuration for the gateway will be generated and saved
also into the project folder.
b.- If NO is selected, remember that the binary file with the project needs to be generated before the
Intesis starts to work as expected.
3.- Press the Send File button to send the binary file to the Intesis device. The process of file transmission
can be monitored in the Intesis Communication Console window. Intesis will reboot automatically once the
new configuration is loaded.
After any configuration change, do not forget to send the configuration file to the Intesis using button
Send File.
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
Figure 3.4 Intesis MAPS Receive/Send tab
User Manual r1.1 eng
URL
https://www.intesis.com
13 / 17
