Unlock Setting - Optex IVPC-DI Installation Manual

1
Mounting and wiring
1
Turn off all equipment including
the external devices of the system.
OFF
4
Wire to the terminals.
NOTE
Polarity is not a concern.
2
Pairing
1
Press the doorbell on IVPC-DS to
be paired with the IVPC-DI.
3

Unlock setting

1
Press the "Unlock Setting" button.
2
5
Mount the main unit on the mounting plate.
N.O. (ex. Strike)
Attach
COM
N.C. (ex. Maglock)
Power
10 to 24 V AC/DC
2
After accepting the call, press the icon
shown below to start the wizard for
the IVPC-DI.
2
Select which chime will also
function as a door release.
NOTE
One IVPC-DS can pair up to four IVPC-DI. However, only one IVPC-DI can be assigned to
-
operate its relay. The other three are limited to sounding their chimes.
- For example, one IVPC-DI operates the door-lock at the front while a second IVPC-DI serves
as a chime in a back room.
- The chimes sound simultaneously with the same type of tone.
Remove the main unit
from the mounting plate.
1
2
Pull off.
Slide up.
1
2
Slide down.
- 2 -
3
Pass the wires through and fix
the mounting plate to the wall.
6
Turn on all equipment.
ON
3
Confirm the correct number of paired
chimes is shown at the completion of
the wizard.
"Unlock" marking is indicated
on the assigned IVPC-DI.
