LECTUS duo 3000
2.1.6 Configuring the reader
The reader provides an 8-way DIP switch for configuration.
Dip switch S1 controls the reader interface type:
Reader type
Wiegand
OSDP
Dip switch S2 is reserved.
Dip switches S3 and S4 controls the data record type:
Data record type
Read CSN only
Read Bosch code only
Auto detect CSN/Bosch code
Reserved
NOTICE!
The DIP switches 5 to 8 are not applicable to Wiegand readers.
They get their addresses from the reader interface of the
AMC2 4W.
Bosch Access Systems GmbH Technical manual
Technical details | en
Setting switch S1
OFF
ON
S3 S4
OFF OFF
ON OFF
OFF ON
ON ON
