Product information Function The exodraft CFI Inline fan is intended for use as a true in-line draft inducer. It can be installed in-line in the vertical or horizontal section of the fluepipe. It is specifically designed for applications where reliable and efficient operation, low noise level, low energy consumption, variable speed and compact design are critical.
If other components are shipped, these will appear as separate items on the shipping packing list. Warranty exodraft provides a two-year factory warranty on its flue gas fans, valid from invoice date. exodraft fans must be installed by competent personnel.
3110067 CFI 300-500 UK 290415 Technical specifications • 5 Specifications Dimensions exodraft In-line Fan Model CFI 300 CFI 350 CFI 400 CFI 500 Fan Type Centrifugal Impeller (B-wheel) Motor Type TEFC Voltage 1 x 230 3 x 230 Frequency Amperage...
Mechanical installation General WARNING Failure to install, maintain and/or operate the exodraft CFI Inline fan in accordance with the manufacturer’s instructions may result in conditions which can produce bodily injury and property damage. The CFI must be installed by a qualified installer in accordance with these instructions and all local codes.
Mechanical Installation • 7 3110067 CFI 300-500 UK 290415 Drain installation Install the provided drain if the CFI is mounted in position B or C. The drain should be installed near the outlet of the fan and oriented so it points toward the ground.
8 • Mechanical Installation 3110067 CFI 300-500 UK 290415 Vertical installation To mount the CFI vertically, suspend the Inline fan with threaded rod. Once the position of the fan and rods is finalized, hang 4 pieces of threaded rod through the mounting holes of the fan as shown in fig. 7. (On back side of fan, run threaded rod through both top and bottom mounting holes.) Once the Inline fan is leveled, secure the rod with lock...
The isolation switch must comply with national wiring standards. *Please refer to Machine Directive (2006/42/EF/-EEC/-EWG/-CEE) – Appendix 1item 1.6.3 “Separation of the sources of energy” The isolation switch must be ordered separately, as it is not part of the standard exodraft chimney fan delivery.
3110067 CFI 300-500 UK 290415 10 • Electrical installation Wiring Diagram – CFI 400-500 CFI 400 and CFI 500 requires 3 x 230 V AC. The diagram shows the correct wiring in the connection box on the motor. 230/3/60 V AC...
3. Apply power, and check that the impeller is rotating in the direction of the arrow on the side of the motor housing (does not apply to CFI 300, 350). All exodraft fans run in a clockwise direction when viewed looking from the motor side.
General The exodraft Inline fan is designed for prolonged use, and no regular maintenance is required. This specifically applies in case it is being used with fuel oil. The Inline fan is designed to make this an easy task. The front part of the venter has the motor and impeller mounted on it, and it slides out to provide easy access.
3110067 CFI 300-500 UK 290415 Maintenance and troubleshooting • 13 Troubleshooting Problem Possible Cause Solution The fan is not operating – No power to the fan – Check the power supply wires in the junction box by the fan. – Check the circuit breaker.
Page 14
14 • EU declaration of conformity 3110067 CFI 300-500 UK 290415 EU declaration of Conformity Declaration of Conformity DK: EU-Overensstemmelseserklæring NL: EU-Conformiteits verklaring GB: Declaration of Conformity SE: EU-Överensstämmelsedeklaration DE: EU-Konformitätserklärung EU-Vaatimustenmukaisuusvakuutus FR: Déclaration de conformité de l’Union Européenne IS: ESS-Samræmisstaðfesting NO: EU-Samsvarserklæring...
