General Information - Fayat Bomag BW 900-50 Service Manual

Overview of machine - General information

3.1 General information

Fig. 29
52
3.1 General information.................................................. 52
3.2 Electric systems....................................................... 53
3.3 Hydraulic system...................................................... 55
3.4 Machine assemblies................................................. 56
3.4.1 Engine...................................................................... 56
3.4.2 Oscillating articulated joint....................................... 57
3.4.3 Drums...................................................................... 59
Areas of application: Earthwork and asphalt construction.
New build and repair work in medium to small construction proj-
ects, car parks, pavements and paths, bicycle lanes, playgrounds
and sports grounds, as well as finishing work in road construction.
BW 900-50
S-834-0002
